Forsizesabove112Athefrontterminalcoverhastoberemovedwhenusingtheabovelistedlugs.
Thefollowingsizesareprovidedwithterminalblocks:
U/V/W/C/D: AWG5-3/0(16-95mm2),strandedCu
PE:  AWG5-1(16-50mm2),strandedCu
ThefollowingAWGandtorquearerequiredforeldwiring:
Device type AWG Tightening torque [Nm]
TPD32-EV-.../...-88-.. 2 12
TPD32-EV-.../...-112-.. 1/0 12
TPD32-EV-.../...-148-.. 3/0 12
Grounding - 12
note!  Whenconnectingtheconverter,a9.5mm(3/8in.)spacingbetweenuninsulatedlivepartsof
oppositepolarityshouldbemantained.
note!  TheTPD32-EVconvertersareULlistedonlywhenusedwiththeabovementionedterminal
kits.
Table 4.3.5: Wire adapter Kit and lugs suggested for UL approval
Device type Terminals Wire adapter kit Recommended lugs
type Kit bolt size
[mm]
Tightening
torque [Nm]
ILSCO type Burndy type Grainger type
TPD32-EV-.../...-148-....-A-NA
U, V, W - - - - - -
C, D EAM 1578 M8 15 CCL-4/0-516 YA28-L3 -
PE - - - - - -
TPD32-EV-.../...-224-..-B-NA
U, V, W - - - CCL-2/0-12
YA1CL6-BOX
-
C, D - - - CCL-2/0-12
YA26L6-BOX
-
PE - - - CRA-2/0, CCL-2/0-38 YA26-LBOX -
TPD32-EV-.../...-280-..-B-NA
U, V, W - - - CCL-4/0-12
YA26L6-BOX
-
C, D - - - CCL-4/0-12
YA27L-BOX
-
PE - - - CRA-2/0, CCL-2/0-38 YA26-LBOX -
TPD32-EV-.../...-336-..-B-NA
U, V, W - - - CCL-4/0-12
YA27L-BOX
-
C, D - - - CRA-300, CRA-300L
YA29L-BOX
-
PE - - - CRA-2/0, CCL-2/0-38 YA26-LBOX -
TPD32-EV-.../...-400-..-B-NA
U, V, W
2 x 250
M10 25 -
YA29L-BOX,
-
C, D
EAM1579
M10 25 -
YA30L
-
PE - - - CRA-2/0, CCL-2/0-38 YA26-LBOX -
TPD32-EV-.../...-450-..-B-NA
U, V, W
EAM1580
M14 45 -
YA30L7
-
C, D
EAM1580
M14 45 -
YA32L
-
PE - - - CRA-2/0, CCL-2/0-38 YA26-LBOX -
TPD32-EV-.../...-490-..-C-NA
U, V, W - 2 x M10 25 - YA27L-BOX -
C, D - 2 x M10 25 - YA26L6-BOX -
PE - - - - - -
TPD32-EV-.../...-560-..-C-NA
U, V, W - - - CCL-4/0-12
YA27L-BOX
-
C, D - - - CRA-250, CRA-250L
YA26L6-BOX
-
PE - - - CRA-2/0, CCL-2/0-38 YA26-LBOX -
TPD32-EV-.../...-750-..-C-NA
U, V, W
4 x 4/0
2 x M10 25 -
YA28L-BOX
-
C, D
EAM1581
M10 25 -
YA30L
-
PE
2/0
- - CRA-2/0, CCL-2/0-38
YA26L6-BOX
-
TPD32-EV-.../...-800-..-C-NA
U, V, W - M10 25 CRA-250 o CRA-250L - -
C, D - M10 25 CRA-250 o CRA-250L - -
PE -
TPD32-EV-.../...-850-..-C-NA
U, V, W EAM 1581 M10 25 - YA30-L -
C, D M10 25 - YA32-L1 -
PE - - - CRA-2/0, CCL-2/0-38 YA26-LBOX -
TPD32-EV-.../...-980-..-D-NA
U, V, W EAM2617_2 4 x M12 45 - - 3LM57
C, D - 4 x M12 45 - - 3LM61
PE - 4 x M12 45 - -
TPD32-EV-.../...-1000-..-D-NA
U, V, W EAM2617_2 4 x M12 45 - - 3LM57
C, D - 4 x M12 45 - - 3LM61
PE - 4 x M12 45 - -
