6.14.8 Brake control
FUNCTIONS
Brake control
[1295] EnableTorquepr
[1262] Closingspeed[rpm]
[1293] Torquedelay[ms]
[1294] Torqueproving[%]
[1266] Actuatordelay[ms]
Parameter description No.
Value
Standard
Conguration
min max
Factory
American
Factory
Standard
Enable Torque pr
1295 0 1 Disabled Disabled
-
Closing speed [rpm]
1262 0 200 30 30
-
Torque delay [ms]
1293 0 30000 3000 3000
-
Torque proving [%]
1294 0 200 75 75
-
Actuator delay [ms]
1266 0 30000 1000 1000
-
Thepurposeofthisfunctionistomakesurethedrivegeneratessufcienttorquetosupporttheloadofcranes
orotherhoistingequipment,duringthebrakereleasetransientphase.
Enable Torque pr Enablesthemechanicalbrakecontrolfunction.Itisusedtoapplyatorquecapableof
sustainingaloadduringthetransientphaseofreleasing/openingthebrake.
Closing speed Aftersendingastopcommandtothedrive,thisisthespeedofthemotorforwhichthe
brakeisclosed.
Torque delay Thedelay,afterastartcommand,withinwhichthebrakeopeningtransientphasemust
becompletedsothatthe“BrakeFault”alarmisnotenabled.
Torque proving Thevalueofthecurrentcapableofsustainingtheloadbeforethebrakeisreleased
(percentageofFLC).ThiscanbesetviaparameteroranaloginputsetasBrake Ref
(32).
Actuator delay Thetimefromwhenanopenbrakecommandissentuntilthereferenceisactive.
