—————— TPD32-EV ——————
78
4.6.1
Assignment of the plug-in terminal strip (terminals 1...15) for Option Card TBO
Table 4.6.1.1: Terminal strip connections
Designation Function I/O Max
voltage
Max
current
1
Analog output 3
Analog output 3
Reference point: Terminal 2
Factory set for T current (motor current)
O ±10V 5mA
2
COM analog
output 3
Reference point of analog output 3 (Terminal 1) — — —
3
Analog output 4
Analog output 4
Reference point: Terminal 4
Factory set for motor speed ( Current U)
O ±10V 5mA
4
COM analog
output 4
Reference of analog output 4 (Terminal 3) — — —
5
COM digital
outputs
COM digital outputs (Terminals 6...9) — — —
6
Digital output 5
Digital output 5
COM: Terminal 5
Factory set for Ramp + (Curr limit state)
O +30V 50mA
7
Digital output 6
Digital output 6
COM: Terminal 5
Factory set for Ramp - (Overvoltage)
O +30V 50mA
8
Digital output 7
Digital output 7
COM: Terminal 5
Factory set for Spd threshold (Undervoltage)
O +30V 50mA
9
Digital output 8
Digital output 8
COM: Terminal 5
Factory set for Overload available (Overcurrent)
O +30V 50mA
10
Supply digital
outputs
Supply voltage for digital outputs I +30V
depends on
the load
max 80mA
11
Digital input 5
Digital input 5
COM: Terminal 15
Not Factory set
I +30V
15V/3.2mA
24V/5mA
30V/6.4mA
12
Digital input 6
Digital input 6
COM: Terminal 15
Not Factory set
I +30V
15V/3.2mA
24V/5mA
30V/6.4mA
13
Digital input 7
Digital input 7
COM: Terminal 15
Not Factory set
I +30V
15V/3.2mA
24V/5mA
30V/6.4mA
14
Digital input 8
Digital input 8
COM: Terminal 15
Not Factory set
I +30V
15V/3.2mA
24V/5mA
30V/6.4mA
15
COM digital
inputs
COM of the digital inputs (Terminals 11...14) — —
Table 4.6.1.2: Cable size for terminals of the option card TBO
Terminals Max cable connection section Tightening torque
(Nm)
flexible (mm) multi-core (mm) AWG
1...15 0,14...1,5 0,14...1,5 28...16 0,4
Theuseofa3x0.1x0.02inches(75x2.5x0.4mm)atscrewdriverisrecommended.Striptheendsofthe
cablestoalengthof0.26inch(6.5mm).Onlyoneunpreparedwire(withoutferrule)shouldbeconnectedto
eachterminal.
