—————— TPD32-EV ——————
240
Multi speed sel ItisthewordrepresentationofthethreeparametersSpeed sel 1(bit0),Speed sel 2 (bit1)
andSpeed sel 3 (bit2).Usedtochangethespeedselectionbychangingonlyonepa-
rameterinsteadofthree.ThisallowsselectingdifferentspeedsviaseriallineorBus
instantaneously.
Thetableandgraphbelowshowtheinteractionbetweentheselectionandthecorrespondingreferencevalue.
REFERENCE
+
0
1
0
1
0
1
0
1
0
0
1
1
0
0
1
1
0
0
0
0
1
1
1
1
Multi speed sel.
0
Ramp ref (d)
Speed sel 0
Bit 0 Not Selected
Speed sel 1
Bit 1 Not Selected
Speed sel 2
Bit 2 Not Selected
Ramp ref 1
0 rpm
Multi speed 3
0 rpm
Multi speed 2
0 rpm
Multi speed 1
0 rpm
Multi speed 4
0 rpm
Multi speed 5
0 rpm
Multi speed 7
0 rpm
Multi speed 6
0 rpm
Ramp ref 2
0 rpm
Enable multi spd
Disabled
Table 6.14.2.1: Multi speed function
7
6
5
4
3
2
1
0
Multi speed 1
Multi speed 2
Multi speed 3
Multi speed 4
Multi speed 5
Multi speed 0
Multi speed 6
Multi speed 7
Speed sel 0
Speed sel 2
Speed sel 1
Figure 6.14.3.2: Multi speed function
InordertooperatetheMultispeedfunction,itmustbeenabledwithEnab multi spd parameter.
TherequiredreferencevalueisselectedwiththeSpeed sel 0,Speed sel 1andSpeed sel 2signals.
Theselectionofthereferencevaluesiscarriedoutviathekeypadortheserialinterface.
Thereferencevaluesaresignedsothattheycanbedenedforaparticularrotationdirectionofthedrive.Asfor
theTPD32-EV...2B...thereferencemusthaveapositivepolarity.
WhentheMultispeedfunctionisenabled,Multi speed 0isdenedbytheadditionofthereferencevalues
Ramp ref 1andRamp ref 2.
