Table 4.4.3: Dip-switch S4 adaptation of the tachometer feedback to the input voltage
Tacho voltage
full scale (V)
S4-1
S4-8
S4-2
S4-7
S4-3
S4-6
S4-4
S4-5
22.7 ON ON ON ON
45.4 ON ON ON OFF
90.7 ON ON OFF OFF
181.6 ON OFF OFF OFF
302.9 OFF OFF OFF OFF
Table 4.4.4: Jumpers on the Regulator card
Designation Function Factory
S4 Matching of the input voltage of the tachogenerator reaction, see table 4.4.3
S5,S6
Adaptation of the speed feedback type:
B
Pos. A Sinusoidal encoder
Pos. B Tachogenerator
Any position: digital encoder, armature feedback
S9
Adaptation to the signal of the analog input Input 1 (terminals 1 and 2)
OFFON 0 ... 20 mA / 4 ... 20 mA
OFF 0 ... 10V / -10 ... +10V
S10
Adaptation to the signal of the analog input Input 2 (terminal 3 and 4)
OFFON 0 ... 20 mA / 4 ... 20 mA
OFF 0 ... 10V / -10 ... +10V
S11
Adaptation to the signal of the analog Input 3 (terminals 5 and 6)
OFF
ON 0 ... 20 mA / 4 ... 20 mA
OFF 0 ... 10V / -10 ... +10V
S12 / S13
Terminating resistor for the serial interface RS485
OFFON Interface terminated with resistor
OFF Interface not terminated
S14 Field current resistors setting, see table 2.4.3.2
S15
Adaptation of the regulation card to the device type, see table 4.4.2
S18 / S19
Selection of the internal/external supply of the RS485 serial interface
OFF
OFF Serial interface supplied from the outside (PIN 5 and 9) and galvanic divided form the regula-
tion section.
ON Serial interface supplied from the inside and connected to the potential reference point of the
regulation. PIN 5 and 9 are used to supply the adaptor of the serial interface.
S20
Monitoring of the C channel of the digital encoder on connector XE2
OFFON C-channel monitored
OFF C-channel not monitored
S21 / S22 / S23
Encoder supply voltage selection
OFFON 5 V encoder supply voltage
OFF 15...30 V encoder supply voltage
ONMountedJumpers OFFNonmountedJumpers
Table 4.4.5: Test points on Regulator card
Test point Function Test point Function
XY20
Monitoring (± 10VDC) of the Select output parameters set-
ting. (Using this test point set all the Select output 1,2,3,4
to the variable that has to be measured).
XY17
Output current signal
(0.61 V =Nominal Drive output current)
XY10 Reference point XY18 Reference point
345678910 11 12 13 14 15 16 17 18 19 2012
23 24 25 26 27 28 29 30 31 32 33 34 37 38 39 40 41 4221 22
Figure 4.4.2: Disposition of terminals from 1 to 42
