—————— Instruction manual ——————
361
BIT
7 6 5 4 3 2 1 0
Status no.1 Drive disabled 0 1 0 0 0 0 0 0
Status no.2 Drive enabled & start; No Alarms active 0 0 1 1 0 1 1 1
Status no.3 Drive enabled & start; Warning active 1 0 0 1 1 1 1 1
Status no.4 Drive disabled; Warning active; start not possible 1 0 0 0 1 0 0 0
Status no.5 Drive disabled; Warning active; start possible 1 1 0 0 0 0 0 0
Status no.6 Drive disabled; Fault active (alarm set as activity > Warning) 0 0 0 0 1 0 0 0
Status no.7 Drive enabled & start; Fault active (alarm set as activity >
Warning that cause drive stop) with no previous Warning
condition
0 0 0 1 1 0 0 0
Status no.8 Drive enabled & start; Fault active (alarm set as activity >
Warning that cause drive stop) with previous Warning condition
1 0 0 1 1 0 0 0
nota! Bit 0, 1, 2 of Status no.7 and Status no.8: whenthemotorisrunning(driveenabled)the
valueofbits1,2,3is1(one).Wheneverafaultoccours(thatdisablesthedrive),themotor
willstop.Whenthemotorspeedis0(zero)the3bitschangefrom1to0.
BITs Description
BIT Description
0,1,2 Motor regulation Active (Drive enabled and start, No fault)
3 Malfunctioning Active (Fault or/and warning)
Except when the drive is disabled and/or Alarm activity set to warning which does not prevent activation of
motor
4 Drive enabled and start (is set to 0 (zero) if enable=0 and start=0.
If a drive fault is shown it remains to 1 (one) until Enable command and Start is not removed (set to = 0 (zero))
5 Drive enabled and NO Malfunctioning situation
6 Drive disabled and no fault
7 Warning active
Note : this bit is set to 1 (one) also when command RL Search is selected. Both when drive is disabled and dur-
ing autotuning procedure)
6.18.2 Speed
DRIVECOM
[44] Speedinputvar[FF]
[115] Speedrefvar[FF]
[119] Actspeedvalue[FF]
[45] Speedbasevalue[FF]
[46] Speedinputperc[%]
[116] Percentrefvar[%]
[120] Actpercentage[%]
Parameter description No.
Value
Standard
Conguration
min max
Factory
American
Factory
Standard
Speed input var [FF]
44 -2P45 +2P45 0 0
*
Speed ref var [FF]
115 -32768 +32767 - -
**
Act speed value [FF]
119 -32768 +32767 - -
***
Speed base value [FF]
45 1 16383 1500 1500
Speed input perc [%]
46 -32768 +32767 0 0
*
Percent ref var [%]
116 -32768 +32767
**
Act percentage [%]
120 -32768 +32767
***
*FactorysetasRamprefandconnectedtoanaloginput1(terminal1and2).Seereferencevalues.
** FactorysetasSpeedrefandconnectedtotherampoutput.Seereferencevalues.
***FactorysetasMotorspeedandconnectedtoanalogoutput1.SeeBASICMENU.
