TPD32 EV
American sizes
Quantity
American
Type Code
TPD32 EV-.../...-....-..-A-NA 2 500 V 16 A fast S824B
TPD32 EV-.../...-....-..-B-NA 2 600 V 25 A fast S823B
TPD32 EV-.../...-....-..-C-NA 2 600 V 25 A fast S823B
TPD32 EV-.../...-920-..-D to TPD32 EV-.../...-1500-..-D-NA 2 600 V 50 A fast F4M15
TPD32 EV-.../...-1650-..-D to TPD32 EV-.../...-1850-..-D-NA 2 600 V 100 A fast F4M21
TPD32 EV-.../...-1000-..-E to TPD32 EV-.../...-1500-..-E-NA 2 600 V 50 A fast F4M15
TPD32 EV-.../...-1800-..-E to TPD32 EV-.../...-2350-..-E-NA 2 600 V 100 A fast F4M21
Note! Thesefusesareinternallymountedandareprovidedonthedelivery.
Table 4.9.1.5: FU1, FV1, External field circuit fuses for TPD32-EV-CU
TPD32 EV
Standard sizes
Quantity
Standard
Type Code
TPD32-EV-CU-.../...-....-40 2
FWP-50A22Fa
A70QS50-22F
5014006.50
F4M15
TPD32-EV-CU-.../...-....-70 2
FWP-100A22Fa
A70QS100-22F
5.014.006.100
F4M21
note!  Technicalcharacteristicsoffuses,includingsize,weight,dissipation,heat,etc.areprovidedintherelative
fusemanufacturers’catalogues(5014006...=SIBA;FWP…=Bussmann;A70...=Ferraz-Shawmut).
Table 4.9.1.5: Other internal fuses
Construction type Designation Fuses for Fuse Code Mounted on
A F1
+ 24V
power supply out
IEC 250 V 2.50 A slo-blo
0.2” x 0.8” (5 x 20 mm)
S8B29
SW1-31
≥ rev. K (*)
B
F1/F2
+ 24V
power supply out
IEC 250 V 2.50 A slo-blo
0.2” x 0.8” (5 x 20 mm)
S8B29
SW2-32
≥ rev. J (**)
F1/F2/F3 Varistor fuse
IEC 500 V 16 A fast acting
0.24” x 1.26” (6 x 32 mm)
IEC 600 V 15 A fast acting
0.4” x 1.5” (10 x 38 mm)
S824B
S823B
FIR-2-51 (TPD32 EV-
500/...-...)
FIR-2-61 (TPD32 EV-
575/...-...)
C
F1/F2
+ 24V
power supply out
IEC 250 V 2.50 A slo-blo
0.2” x 0.8” (5 x 20 mm)
S8B29 SW3-32
F1/F2/F3 Varistor fuse
IEC 500 V 25 A fast acting
0.24” x 1.26” (6 x 32 mm)
IEC 690 V 25 A fast acting
0.55” x 2” (14 x 51 mm)
IEC 690 V 25 A fast acting
0.55” x 2” (14 x 51 mm)
S821B
S85B6
S85B6
FL-31
FL-57 (TPD32 EV-
575/...-...)
FL-69 (TPD32 EV-
690/...-...)
D
F1
+ 24V
power supply in
IEC 250 V 2.50 A slo-blo
0.2” x 0.8” (5 x 20 mm)
S8B29 SW1-31
F11/F21/F31 Varistor fuse
IEC 690 V 10 A fast acting
0.55” x 2” (14 x 51 mm)
S7G49 CFSF-..
(*)  F1(SW1-31<rev.K)=IEC250V1Aslo-blo,0.2”x0.8”(5x20mm)
(**)  F1(SW2-32<rev.J)=IEC250V3.15Afastacting,0.2”x0.8”(5x20mm)
