—————— TPD32-EV ——————
64
4.2 WIRING THE DRIVE
Wirethedriveinaccordancewiththestandardconnectiondiagrams,seechapter"4.8StandardConnection
Diagrams"onpage82
4.3 POWER SECTION
note! Usecopperconductorsonly.
 ForULlistedequipmentsuse75°Cstrandedcopperconductorsonly.
Table 4.3.1: Terminals description
Designation Function I/O max voltage max current min current
U, V, W Connection to the AC mains of the armature circuit I 3 x 690V AC ± 10% see 2.3.2 —
C, D Armature connection O see tab. 2.4.3.3 see 2.3.3 —
U1, V1 * Connection to the AC mains of the field circuit I 1 x 460V AC ± 10% see 2.3.2 —
C1, D1 * Field connection O 0,87 U
LN
see 2.3.3 —
U2, V2 AC power supply regulation I
1 x 115V ±15%
1 x 230V ±15%
see 2.3.2 —
U3, V3
AC mains power supply for internal fan
(Type C-D-E converters only,
see table 2.1.1)
I 1 x 230V AC see 2.5 —
31 / 32
Fan unit power supply relay potential-free NC contact
(Type D-E converters only)
O 250 VAC 1 A AC11 100mA
35 / 36
Contact without potential of OK relay (closed = OK), function as per the
OK relay func parameter in the CONFIGURATION / digital output menu
O 250 VAC 1 A AC11 100mA
75 / 76
Contact without potential of relay 2, function as per Relay 2 parameter in
the I/O CONFIGURATION / digital outputs menu
O 250 VAC 1 A AC11 100mA
78 / 79 Thermistor connection I — — —
81 / 82 Internal fuses intervention signalling
(For types C and D, see table 2.1.1)
O
250 VAC 1 A AC11 50mA
*notincludedinTPD32-EV-FC-...models
Table 4.3.2: Cable size for power terminals U, V, W, C, D, PE
Standard max cable section [mm
2
] AWG Tightening torque [Nm]
TPD32-EV-.../...-20-..-A 4 12 2...3
TPD32-EV-.../...-40-..-A 10 8
2.5...3
TPD32-EV-.../...-70-..-A 16 6
TPD32-EV-.../...-110-..-A 6...50 10...1
12TPD32-EV-.../...-140-..-A
16...95 6...000
TPD32-EV-.../...-185-..-A
TPD32-EV-.../...-280-..-B
Cu-Band 10 x 16 x 0,8 -
25
(PE: 12)
TPD32-EV-.../...-350-..-B
TPD32-EV-.../...-420-..-B
TPD32-EV-.../...-500-..-B
Cu-Band 11 x 21 x 1 -
TPD32-EV-.../...-650-..-C
TPD32-EV-.../...-560-..-C
Cu-Band 50 x 8
or
Cu-Band 2 x 10 x 16 x 0,8
-
TPD32-EV-.../...-700-..-C ...
TPD32-EV-500/...-1050-4B-C
TPD 32-EV-690/...-1300-2B-D ...
TPD32-EV-.../...-1900--D
300 - 45
TPD32-EV-.../...-2000-..-D ...
TPD32-EV-.../...-2400-..-D
300 - 45
