—————— Instruction manual ——————
71
TPD32-EV-690/810-2000-2B-E TPD32-EV-690/810-1500-2B-E-NA
ON OFF OFF ON OFF ON OFF OFF
TPD32-EV-690/810-2400-2B-E TPD32-EV-690/810-1800-2B-E-NA
ON OFF OFF ON OFF ON OFF ON
TPD32-EV-690/810-2700-2B-E TPD32-EV-690/810-2000-2B-E-NA
ON OFF OFF ON OFF ON ON OFF
TPD32-EV-690/810-3300-2B-E TPD32-EV-690/810-2350-2B-E-NA
ON OFF OFF ON ON OFF OFF OFF
Standard American S15-8 S15-7 S15-6 S15-5 S15-4 S15-3 S15-2 S15-1
TPD32-EV-500/520-770-4B-C TPD32-EV-500/520-560-4B-C-NA
OFF ON OFF OFF ON OFF ON ON
TPD32-EV-500/520-1050-4B-C TPD32-EV-500/520-850-4B-C-NA
OFF ON OFF OFF ON ON OFF OFF
TPD32-EV-500/520-1400-4B-D TPD32-EV-500/520-1000-4B-D-NA
OFF ON OFF ON ON OFF ON ON
TPD32-EV-500/520-1600-4B-D TPD32-EV-500/520-1200-4B-D-NA
OFF ON OFF ON ON ON OFF OFF
TPD32-EV-500/520-2000-4B-D TPD32-EV-500/520-1500-4B-D-NA
OFF ON OFF ON OFF OFF OFF ON
TPD32-EV-500/520-2400-4B-D TPD32-EV-500/520-1850-4B-D-NA
OFF ON ON OFF OFF OFF OFF ON
TPD32-EV-500/520-1500-4B-E TPD32-EV-500/520-1300-4B-E-NA
OFF ON OFF OFF ON ON ON ON
TPD32-EV-500/520-1700-4B-E TPD32-EV-500/520-1350-4B-E-NA OFF ON OFF ON OFF OFF OFF OFF
TPD32-EV-500/520-2000-4B-E TPD32-EV-500/520-1500-4B-E-NA
OFF ON OFF ON OFF OFF OFF ON
TPD32-EV-500/520-2400-4B-E TPD32-EV-500/520-1800-4B-E-NA
OFF ON OFF ON OFF OFF ON OFF
TPD32-EV-500/520-2700-4B-E TPD32-EV-500/520-2000-4B-E-NA
OFF ON OFF ON OFF OFF ON ON
TPD32-EV-500/520-3300-4B-E TPD32-EV-500/520-2350-4B-E-NA
OFF ON OFF ON OFF ON OFF ON
TPD32-EV-575/600-280-4B-B TPD32-EV-575/600-224-4B-B-NA
ON OFF OFF OFF OFF ON ON OFF
TPD32-EV-575/600-350-4B-B TPD32-EV-575/600-280-4B-B-NA
ON OFF OFF OFF OFF ON ON ON
TPD32-EV-575/600-420-4B-B TPD32-EV-575/600-336-4B-B-NA
ON OFF OFF OFF ON OFF OFF OFF
TPD32-EV-575/600-500-4B-B TPD32-EV-575/600-400-4B-B-NA
ON OFF OFF OFF ON OFF OFF ON
TPD32-EV-575/600-650-4B-B TPD32-EV-575/600-450-4B-B-NA
ON OFF OFF OFF ON OFF ON OFF
TPD32-EV-575/600-700-4B-C TPD32-EV-575/600-490-4B-C-NA
ON OFF OFF ON OFF ON ON ON
TPD32-EV-575/600-1050-4B-C TPD32-EV-575/600-750-4B-C-NA
ON OFF OFF ON ON OFF OFF ON
TPD32-EV-575/600-1300-4B-D TPD32-EV-575/600-980-4B-D-NA
ON OFF OFF ON ON OFF ON OFF
TPD32-EV-575/600-1600-4B-D TPD32-EV-575/600-1200-4B-D-NA
ON OFF OFF ON ON ON OFF OFF
TPD32-EV-575/600-2000-4B-D TPD32-EV-575/600-1500-4B-D-NA
ON OFF OFF ON OFF OFF OFF ON
TPD32-EV-575/600-2300-4B-D TPD32-EV-575/600-1800-4B-D-NA
ON OFF ON OFF OFF OFF OFF OFF
TPD32-EV-690/720-560-4B-C TPD32-EV-690/720-360-4B-C-NA
ON OFF OFF ON OFF ON ON OFF
TPD32-EV-690/720-700-4B-C TPD32-EV-690/720-490-4B-C-NA
ON OFF OFF ON OFF ON ON ON
TPD32-EV-690/720-900-4B-C TPD32-EV-690/720-650-4B-C-NA ON OFF OFF ON ON OFF OFF OFF
TPD32-EV-690/720-1300-4B-D TPD32-EV-690/720-980-4B-D-NA
ON OFF OFF ON ON OFF ON OFF
TPD32-EV-690/720-1600-4B-D TPD32-EV-690/720-1200-4B-D-NA
ON OFF OFF ON ON ON OFF OFF
TPD32-EV-690/720-1900-4B-D TPD32-EV-690/720-1450-4B-D-NA
ON OFF OFF ON ON ON ON OFF
TPD32-EV-690/720-2100-4B-D TPD32-EV-690/720-1650-4B-D-NA
ON OFF OFF ON ON ON ON ON
TPD32-EV-690/720-1010-4B-E TPD32-EV-690/720-900-4B-E-NA
ON OFF OFF OFF ON ON OFF ON
TPD32-EV-690/720-1400-4B-E TPD32-EV-690/720-1150-4B-E-NA
ON OFF OFF OFF ON ON ON OFF
TPD32-EV-690/720-1700-4B-E TPD32-EV-690/720-1350-4B-E-NA ON OFF OFF ON OFF OFF OFF OFF
TPD32-EV-690/720-2000-4B-E TPD32-EV-690/720-1500-4B-E-NA
ON OFF OFF ON OFF OFF OFF ON
TPD32-EV-690/720-2400-4B-E TPD32-EV-690/720-1800-4B-E-NA
ON OFF OFF ON OFF OFF ON OFF
TPD32-EV-690/720-2700-4B-E TPD32-EV-690/720-2000-4B-E-NA
ON OFF OFF ON OFF OFF ON ON
TPD32-EV-690/720-3300-4B-E TPD32-EV-690/720-2350-4B-E-NA
ON OFF OFF ON OFF ON OFF ON
Table 4.4.2-B: Dip-switch S15 Adjustment of the TPD32-EV-CU-... series mains voltage regulation card
Standard American
S15-8 S15-7 S15-6 S15-5 S15-4 S15-3 S15-2 S15-1
TPD32-EV-CU-230/500-THY1-FC40 TPD32-EV-CU-230/500-THY1-FC40
OFF ON ON ON ON ON ON ON
TPD32-EV-CU-230/500-THY2-FC40 TPD32-EV-CU-230/500-THY2-FC40
OFF ON ON ON ON ON ON ON
TPD32-EV-CU-230/500-THY1-FC70 TPD32-EV-CU-230/500-THY1-FC70
OFF ON ON ON ON ON ON ON
TPD32-EV-CU-230/500-THY2-FC70 TPD32-EV-CU-230/500-THY2-FC70
OFF ON ON ON ON ON ON ON
TPD32-EV-CU-575/690-THY1-FC40 TPD32-EV-CU-575/690-THY1-FC40
ON OFF ON ON ON ON ON ON
TPD32-EV-CU-575/690-THY2-FC40 TPD32-EV-CU-575/690-THY2-FC40
ON OFF ON ON ON ON ON ON
TPD32-EV-CU-575/690-THY1-FC70 TPD32-EV-CU-575/690-THY1-FC70
ON OFF ON ON ON ON ON ON
TPD32-EV-CU-575/690-THY2-FC70 TPD32-EV-CU-575/690-THY2-FC70
ON OFF ON ON ON ON ON ON
note!  Thedriveratedcurrentvaluemustbesetinparameter465"DriveSize".SwitchesSW3and
SW4onthe“FIR”powercardmustalsobecongured.(see"11.1Hardwareconguration"
onpage471).
