4.9.2 Fuses selection when the Overload function is activated
 >100%for60seconds-StandardSetting >150%for60seconds-AmericanSetting
Differentfusesmustbeusedwhenthecurrentishigherthantheratedone(overloadcurrent).Maximumvalues
allowedforeachtypearelistedonthenexttable.Becarefulltocoordinatetherightdimension.
Example:the1stfusetypeonpowersectionAhavetobecoordinatedwiththe1stfusetypeonsectionBandsoon.
FortypeC-D-Econverters:see"Table4.9.1.3:Fc,Internalinputsidefuses"onpage88.
Table 4.9.2.1: Fa, Overload fuses
Converter type Code Pieces 400 VAC Input supply 500 VAC Input Supply 575 VAC Input Supply
TPD32-EV-.../...-20-..-A
Fa 3 Z14gR25 (GRD2/25) Z14gR25 (GRD2/25)
Fb* 2 Z14gR32 (F4M11) Z14gR32 (F4M11)
TPD32-EV-.../...-40-..-A
Fa 3 Z22gR50 (F4M15) Z14gR40 (GRD3/35)
Fb* 2 Z22gR63 (F4M17) Z22gR50 (F4M15)
TPD32-EV-.../...-70-..-A
Fa 3
S00C+/üf1/80/100A/660V
(F4EAG)
S00C+/üf1/80/100A/660V
(F4EAG)
Fb* 2
S00C+/üf1/80/100A/660V
(F4EAG)
S00C+/üf1/80/100A/660V
(F4EAG)
TPD32-EV-.../...-110-..-A
Fa 3
S00C+/üf1/80/100A/660V
(F4EAG)
S00C+/üf1/80/100A/660V
(F4EAG)
Fb* 2
S00C+/üf1/80/125A/660V
(F4EAJ)
S00C+/üf1/80/125A/660V
(F4EAJ)
TPD32-EV-.../...-140-..-A
Fa 3 S00UF1/80/160A/660V (F4EAL) S00UF1/80/160A/660V (F4EAL)
Fb* 2 S00UF1/80/200A/660V (F4G23) S00UF1/80/200A/660V (F4G23)
TPD32-EV-.../...-185-..-A
Fa 3 S00UF1/80/200A/660V (F4G23) S00UF1/80/200A/660V (F4G23)
Fb* 2 S00UF1/80/200A/660V (F4G23) S00UF1/80/200A/660V (F4G23)
TPD32-EV-.../...-280-..-B
Fa 3 S1üF1/110/315A/660V (F4G30) S1üF1/110/315A/660V (F4G30) S00C+/üf01/315A/690V (...)
Fb* 2 S2üF1/110/400A/660V (F4G34) S2üF1/110/400A/660V (F4G34) 170M5242 (...)
TPD32-EV-.../...-350-..-B
Fa 3 S2üF1/110/400A/660V (F4G34) S2üF1/110/400A/660V (F4G34) S1üf01/110/400A/690V (...)
Fb* 2 S2üF1/110/500A/660V (F4E30) S2üF1/110/500A/660V (F4E30) 170M5244 (...)
TPD32-EV-.../...-420-..-B
Fa 3 S2üF1/110/500A/660V (F4E30) S2üF1/110/500A/660V (F4E30) S1üf01/110/500A/690V (...)
Fb* 2 S2üF1/110/630A/660V (F4E31) S2üF1/110/630A/660V (F4E31) 170M6244 (...)
TPD32-EV-.../...-500-..-B
Fa 3 S2üF1/110/630A/660V (F4E31) S2üF1/110/630A/660V (F4E31) 170M4265 (...)
Fb* 2 S2üF1/110/710A/660V (F4G85) S2üF1/110/710A/660V (F4G85) 170M4265 (...)
TPD32-EV-.../...-650-..-B
Fa 3 S2üF1/110/630A/660V (F4E31) S2üF1/110/630A/660V (F4E31) S1üf01/110/630A/690V (...)
Fb* 2 S2üF1/110/710A/660V (F4G85) S2üF1/110/710A/660V (F4G85) 170M6246 (...)
Converter type Code Pieces 400 VAC Input supply 500 VAC Input Supply 575 VAC Input Supply
TPD32-EV-.../...-17-..-A-NA
Fa 3 Z14gR25 (GRD2/25) Z14gR25 (GRD2/25)
Fb* 2 Z14gR32 (F4M11) Z14gR32 (F4M11)
TPD32-EV-.../...-35-..-A-NA
Fa 3 Z22gR50 (F4M15) Z14gR40 (GRD3/35)
Fb* 2 Z22gR63 (F4M17) Z22gR50 (F4M15)
TPD32-EV-.../...-56-..-A-NA
Fa 3
S00C+/üf1/80/100A/660V
(F4EAG)
S00C+/üf1/80/100A/660V
(F4EAG)
Fb* 2
S00C+/üf1/80/100A/660V
(F4EAG)
S00C+/üf1/80/100A/660V
(F4EAG)
TPD32-EV-.../...-88-..-A-NA
Fa 3
S00C+/üf1/80/100A/660V
(F4EAG)
S00C+/üf1/80/100A/660V
(F4EAG)
Fb* 2
S00C+/üf1/80/125A/660V
(F4EAJ)
S00C+/üf1/80/125A/660V
(F4EAJ)
TPD32-EV-.../...-112-..-A-NA
Fa 3 S00UF1/80/160A/660V (F4EAL) S00UF1/80/160A/660V (F4EAL)
Fb* 2 S00UF1/80/200A/660V (F4G23) S00UF1/80/200A/660V (F4G23)
TPD32-EV-.../...-148-..-A-NA
Fa 3 S00UF1/80/200A/660V (F4G23) S00UF1/80/200A/660V (F4G23)
Fb* 2 S00UF1/80/200A/660V (F4G23) S00UF1/80/200A/660V (F4G23)
TPD32-EV-.../...-224-..-B-NA
Fa 3 S1üF1/110/315A/660V (F4G30) S1üF1/110/315A/660V (F4G30) S00C+/üf01/315A/690V (...)
Fb* 2 S2üF1/110/400A/660V (F4G34) S2üF1/110/400A/660V (F4G34) 170M5242 (...)
TPD32-EV-.../...-280-..-B-NA
Fa 3 S2üF1/110/400A/660V (F4G34) S2üF1/110/400A/660V (F4G34) S1üf01/110/400A/690V (...)
Fb* 2 S2üF1/110/500A/660V (F4E30) S2üF1/110/500A/660V (F4E30) 170M5244 (...)
TPD32-EV-.../...-336-..-B-NA
Fa 3 S2üF1/110/500A/660V (F4E30) S2üF1/110/500A/660V (F4E30) S1üf01/110/500A/690V (...)
Fb* 2 S2üF1/110/630A/660V (F4E31) S2üF1/110/630A/660V (F4E31) 170M6244 (...)
TPD32-EV-.../...-400-..-B-NA
Fa 3 S2üF1/110/630A/660V (F4E31) S2üF1/110/630A/660V (F4E31) 170M4265 (...)
Fb* 2 S2üF1/110/710A/660V (F4G85) S2üF1/110/710A/660V (F4G85) 170M4265 (...)
TPD32-EV-.../...-450-..-B-NA
Fa 3 S2üF1/110/630A/660V (F4E31) S2üF1/110/630A/660V (F4E31) S1üf01/110/630A/690V (...)
Fb* 2 S2üF1/110/710A/660V (F4G85) S2üF1/110/710A/660V (F4G85) 170M6246 (...)
Fa ExternalfusesforthearmaturecircuitontheDCside
Fb ExternalfusesforthearmatureconverterontheACinputside
* Necessaryonlyforthefourquadrantfunctioning
Note for sizes 770 ... 1050 A: the armature fuses are internally mounted (see table 4.9.1.1)
