—————— TPD32-EV ——————
492
A2.4 Digital Outputs
Thissectionmodieschapter"6.12.3DigitalOutputs"onpage216.
• Addedselectionsneededfor“Ext wired FC”:
Digital output XX Selectionoftheparameterthatisassignedtothedigitaloutputconcerned.Thefollowing
assignmentsarepossible:
OFF
Speed zero thr
Spd threshold
Set speed
Curr limit state
Drive ready
Mot ovrld avail
6)
Overload state
Ramp +
Ramp -
Speed limited
Undervoltage
Overvoltage
Heatsink
Overcurrent
Overtemp motor
External fault
Failure supply
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Pad A bit
Pad B bit
Virt dig input
Torque sign
Stop control
Field loss
Speed fbk loss
Bus loss
Hw opt1 failure
Opt2 failure
Encoder 1 state
Encoder 2 state
Enable seq err
Diameter calc st
1)
Drive healthy
13)
Input 1 cp match
Diam reached
Spd match compl
18
19
20
21
23
24
25
26
28
29
30
31
35
38
42
49
58
59
Acc state
Dec state
Brake comand
2)
Brake failure
3)
Mot ovrld preal
4)
Dvr ovrld preal
5)
Dvr ovrld avail
7)
I2t mot ovrld fail
8)
I2t drv ovrld fail
9)
Mot cur threshld
10)
Overspeed
11)
Delta frequency
12)
Drv rdy to start
14)
BUS control mode
15)
SSC Error
16)
60
61
62
63
65
66
67
68
69
70
71
72
76
77
79
Wired FC Enabled
17)
Wired FC Inv Seq
18)
Wired FC Act Brg
19)
80
81
82
17)
EnableseldcontrolbyTPD32-EV-FCviastandardI/O.
18)
Indicationifeldcontrolisduringinversionsequence
19)
Indicationoftheactualactivebridge(positiveornegative)oftheFCunit.
note: FortheoperationoftheFCunitbyusingexternalI/Osignals,thethreedigitaloutputsofthe
FCunit,conguredasindicatedinsection"A2.5.2ConnectionbetweenTPD32-EV-CUand
TPD32-EV-FCunitsviaexternalI/O"onpage495,mustbeconnectedtothedigitalinputs
oftheCUconguredinthesameway.Inaddition,theanalogoutputoftheCUcongured
as"Field cur ref"mustbeconnectedtoananaloginputunitconguredasFC"T current
ref 1."
