gefran TPD32-EV-...-4B User Manual

—————— TPD32-EV ——————
74
24
COM analog output 2
Reference of analog output 2 — — —
25
COM digital outputs
COM digital outputs (Terminals 26…29) — — —
26
Digital output 1
Digital output 1
COM: Terminal 25
Factory set for Ramp +
O +30V 50mA
27
Digital output 2
Digital output 2
COM: Terminal 25
Factory set for Ramp -
O +30V 50mA
28
Digital output 3
Digital output 3
COM: Terminal 25
Factory set for Spd threshold
O +30V 50mA
29
Digital output 4
Digital output 4
COM: Terminal 25
Factory set for Overload available
O +30V 50mA
30
Supply digital output
Supply voltage for digital outputs I +30V
depends on
the load
max 80mA
31
Digital input 1
Digital input 1
COM: Terminal 37
Not Factory set
I +30V
15V/3,2mA
24V/5mA
30V/6,4mA
32
Digital input 2
Digital input 2
COM: Terminal 37
Not Factory set
I +30V
15V/3,2mA
24V/5mA
30V/6,4mA
33
Digital input 3
Digital input 3
COM: Terminal 37
Not Factory set
I +30V
15V/3,2mA
24V/5mA
30V/6,4mA
34
Digital input 4
Digital input 4
COM: Terminal 37
Not Factory set
I +30V
15V/3,2mA
24V/5mA
30V/6,4mA
37
COM digital inputs
COM of the digital inputs (Terminals 31…34) — —
38 … 42 Not used
Table 4.4.7: Cable size for fans, signals, and thermistors
Terminals Max connection cable section Tightening torque
[Nm]
flexible [mm
2
] multi-core [mm
2
] AWG
1...20, +, - 0,14...1,5 0,14...1,5 26...16 0,4
Theuseofa3x0.1x0.02inches(75x2.5x0.4mm)atscrewdriverisrecommended.Remove0.26inches(6.5mm)
oftheinsulationatthecableends.Onlyoneunpreparedwire(withoutferrule)shouldbeconnectedtoeachterminal.
