10.2 LIST OF HIGH PRIORITY PARAMETERS
WhenaAPC300cardsisusedasubsetoftheTPD32-EVparameterscanbeexchangedwiththeoptionalcard
throughtheautomaticsynchronouscommunication.FormoredetailsseetheAPC300technicaldocumentation.
Parameter No. Format Value Read/
Write
min max factory
Tcurrentlim+[CURR] 8 U16 0 2*TOP_CURR TOP_CURR R/W
Tcurrentlim-[CURR] 9 U16 0 2*TOP_CURR TOP_CURR R/W
InuseTcurlim+[CURR] 10 U16 0 2*TOP_CURR - R
InuseTcurlim-[CURR] 11 U16 0 2*TOP_CURR - R
Currentlimred[CURR] 13 U16 0 2*TOP_CURR TOP_CURR R
Tcurrentref1[CURR] 39 I16 -2*TOP_CURR +2*TOP_CURR 0 R/W
Tcurrentref2[CURR] 40 I16 -2*TOP_CURR +2*TOP_CURR 0 R/W
Tcurrentref[CURR] 41 I16 -2*TOP_CURR +2*TOP_CURR - R
Speedref1[SPD] 42 I16 -32767 32767 0 R/W
Speedref2[SPD] 43 I16 -32767 32767 0 R/W
Rampref1[SPD] 44 I16 -32767 32767 0 R/W
Rampref2[SPD] 48 I16 -32767 32767 0 R/W
Controlword 55 U16 R/W
Statusword 56 U16 R
Rampref[SPD] 110 I16 -32767 32767 - R
Rampoutp[SPD] 113 I16 -32767 32767 - R
Speedref[SPD] 118 I16 -32767 32767 - R
Actualspd[SPD] 122 I16 -32767 32767 - R
Adapreference[SPD] 183 I16 -32767 32767 4000 R/W
Enc1position[ENC_PLS]* 197 I16 -32767 32767 - R
Enc2position[ENC_PLS]* 198 I16 -32767 32767 - R
Enc1lasttime[ENC_TIM]* 204 U32 0 2
32
-1 - R
Enc1lasttimehigh[ENC_TIM]* 205 U16 0 65535 - R
Enc2lasttime{ENC_TIM]* 206 U32 0 2
32
-1 - R
Enc2lasttimehigh{ENC_TIM]* 207 U16 0 65535 - R
Speedregoutput[CURR] 236 I16 -2*TOP_CURR +2*TOP_CURR - R
Lockspeedreg 322 U16 0 1 0 R/W
Enc2speed[SPD]* 420 I16 -37767 32767 - R
Enc1speed[SPD]* 427 I16 -37767 32767 - R
Fluxcurrentmax 467 U16 819 16384 16384 R/W
Fluxreference 500 U16 0 16384 16384 R
Pad0 503 I16 -32768 32767 0 R/W
Pad1 504 I16 -32768 32767 0 R/W
Pad2 505 I16 -32768 32767 0 R/W
Pad3 506 I16 -32768 32767 0 R/W
Pad4 507 I16 -32768 32767 0 R/W
Pad5 508 I16 -32768 32767 0 R/W
Pad6 509 I16 -32768 32767 0 R/W
Pad7 510 I16 -32768 32767 0 R/W
Pad8 511 I16 -32768 32767 0 R/W
Pad9 512 I16 -32768 32767 0 R/W
Pad10 513 I16 -32768 32767 0 R/W
Pad11 514 I16 -32768 32767 0 R/W
Pad12 515 I16 -32768 32767 0 R/W
Pad13 516 I16 -32768 32767 0 R/W
Pad14 517 I16 -32768 32767 0 R/W
Pad15 518 I16 -32768 32767 0 R/W
BitwordpadA 519 U16 0 65535 0 R/W
BitwordpadB 536 U16 0 65535 0 R/W
Diginputterm 564 U16 0 65535 0 R
Digoutputterm 581 U16 0 65535 0 R
