—————— TPD32-EV ——————
216
6.12.3 Digital Outputs
I/O CONFIG
Digital outputs
[145] Digitaloutput1
[1267] Inversionout1
[146] Digitaloutput2
[1268] Inversionout2
[147] Digitaloutput3
[1269] Inversionout3
[148] Digitaloutput4
[1270] Inversionout4
[149] Digitaloutput5
[1271] Inversionout5
[150] Digitaloutput6
[1272] Inversionout6
[151] Digitaloutput7
[1273] Inversionout7
[152] Digitaloutput8
[1274] Inversionout8
[629] Relay2
[1275] Inversionrelay2
Parameter description No.
Value
Standard
Conguration
min max
Factory
American
Factory
Standard
Digital output 1
145 0 77 Ramp+(8) Ramp+(8)
Inversion out 1
Enabled(1)/Disabled(0)
1267 0 1 Disabled(0) Disabled(0)
Digital output 2
146 0 77 Ramp-(9) Ramp-(9)
Inversion out 2
Enabled(1)/Disabled(0)
1268 0 1 Disabled(0) Disabled(0)
Digital output 3
147 0 77 Spdthr.(2) Spdthr.(2)
Inversion out 3
Enabled(1)/Disabled(0)
1269 0 1 Disabled(0) Disabled(0)
Digital output 4
148 0 77 Overldavail.(6) Overldavail.(6)
Inversion out 4
Enabled(1)/Disabled(0)
1270 0 1 Disabled(0) Disabled(0)
Digital output 5
149 0 77 Currlim.state(4) Currlim.state(4)
Inversion out 5
Enabled(1)/Disabled(0)
1271 0 1 Disabled(0) Disabled(0)
Digital output 6
150 0 77 Over-voltage(12) Over-voltage(12)
Inversion out 6
Enabled(1)/Disabled(0)
1272 0 1 Disabled(0) Disabled(0)
Digital output 7
151 0 77 Under-voltage(11) Under-voltage(11)
Inversion out 7
Enabled(1)/Disabled(0)
1273 0 1 Disabled(0) Disabled(0)
Digital output 8
152 0 77 Over-current(14) Over-current(14)
Inversion out 8
Enabled(1)/Disabled(0)
1274 0 1 Disabled(0) Disabled(0)
Relay 2
629 0 77 Stopctrl(23) Stopctrl(23)
Inversion relay 2
Enabled(1)/Disabled(0)
1275 0 1 Disabled(0) Disabled(0)
