6.15.5 Pads
ThepadsareusedforthedataexchangeamongtheseveralcomponentsofaBussystem.Theycanbecompared
tothevariablesofaPLC.Thegure6.15.5.1showstheoverallstructureofthesystem.Withthehelpofpadsit
ispossibleforexampletosendinformationfromaeldBustoanoptioncard.Allthepadscanbewrittenand
read.Seetheseveralaccesspossibilitiesinsection10,“Parameterlist”.
SPEC FUNCTIONS
Pad Parameters
[503] Pad0
[504] Pad1
[505] Pad2
[506] Pad3
[507] Pad4
[508] Pad5
[509] Pad6
[510] Pad7
[511] Pad8
[512] Pad9
[513] Pad10
[514] Pad11
[515] Pad12
[516] Pad13
[517] Pad14
[518] Pad15
[519] BitwordpadA
[536] BitwordpadB
Parameter description No.
Value
Standard
Conguration
min max
Factory
American
Factory
Standard
Pad 0
503 -32768 +32767 0 0 *,**
Pad 1
504 -32768 +32767 0 0 *,**
Pad 2
505 -32768 +32767 0 0 *
Pad 3
506 -32768 +32767 0 0 *
Pad 4
507 -32768 +32767 0 0 **
Pad 5
508 -32768 +32767 0 0 **
Pad 6
509 -32768 +32767 0 0 -
Pad 7
510 -32768 +32767 0 0 -
Pad 8
511 -32768 +32767 0 0 -
Pad 9
512 -32768 +32767 0 0 -
Pad 10
513 -32768 +32767 0 0 -
Pad 11
514 -32768 +32767 0 0 -
Pad 12
515 -32768 +32767 0 0 -
Pad 13
516 -32768 +32767 0 0 -
Pad 14
517 -32768 +32767 0 0 -
Pad 15
518 -32768 +32767 0 0 -
Bitword pad A
519 0 65535 0 0 ***,****
Pad A Bit 0
520 0 1 0 0 ***,****
Pad A Bit 1
521 0 1 0 0 ***,****
Pad A Bit 2
522 0 1 0 0 ***,****
Pad A Bit 3
523 0 1 0 0 ***,****
Pad A Bit 4
524 0 1 0 0 ***,****
Pad A Bit 5
525 0 1 0 0 ***,****
Pad A Bit 6
526 0 1 0 0 ***,****
Pad A Bit 7
527 0 1 0 0 ***,****
Pad A Bit 8
528 0 1 0 0
Pad A Bit 9
529 0 1 0 0
Pad A Bit 10
530 0 1 0 0
Pad A Bit 11
531 0 1 0 0
Pad A Bit 12
532 0 1 0 0
Pad A Bit 13
533 0 1 0 0
Pad A Bit 14
534 0 1 0 0 *****
Pad A Bit 15
535 0 1 0 0
Bitword pad B
536 0 65535 0 0 ****
Pad B Bit 0
537 0 1 0 0 ****
Pad B Bit 1
538 0 1 0 0 ****
Pad B Bit 2
539 0 1 0 0 ****
Pad B Bit 3
540 0 1 0 0 ****
Pad B Bit 4
541 0 1 0 0 ****
Pad B Bit 5
542 0 1 0 0 ****
Pad B Bit 6
543 0 1 0 0 ****
Pad B Bit 7
544 0 1 0 0 ****
Pad B Bit 8
545 0 1 0 0
