FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
10 Display Module (Only FX3UC-32MT-LT)
10.5 Monitor/Test Mode [Excluding User-Registered Devices]
10.5.4 Test mode operation
There are 3 types of test mode operations, depending on the device type. The 3 operations are explained
below.
→ Refer to Subsection 10.5.1 for test mode subject devices.
1. Data registers [D: D (16-bit), DD (32-bit)]/extended registers [R: R (16-bit), DR (32-bit)/
extended file registers [ER: ER (16-bit), DER (32-bit)]/user-registered devices
1) Perform a monitor mode operation to display the device whose
current value is to be changed.
→ Refer to Subsection 10.5.2 for monitor function operation.
2) Hold the [OK] button for 1 second or longer to switch to the test
mode. The current value begins blinking (refer to fig. at right).
3) Use the [+]/[-] buttons to change the value as desired.
To cancel the operation and return to the "monitor screen", press
[ESC].
4) Press [OK] to register the current value and return to the "monitor screen".
• File register (D)
The display module’s test function cannot be used to change the current value of the file register (D) which
is stored in the program memory.
Button Operation Description
ESC
Cancels the operation and returns to the "monitor
screen".
-
Reduces the value. Hold for 1 second or longer for high-
speed reduction.
+
Increases the value. Hold for 1 second or longer for
high-speed increase.
OK
Registers the current value and returns to the "monitor
screen".
D6 00 02
D6 012
D6 022
D6 032
0
0
0
D6 00 02
D6 012
D6 022
D6 032
0
0
0
D6 002
D6 012
D6 022
D6 032
5
