FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
2 External Dimensions and Terminal Arrangement
2.1 External Dimensions (MASS/Installation/Accessories)
1
Outline
2
External Dimensions
3
Generic Specifications
4
Power Supply Specifications
5
Input Specifications
6
Output Specifications
7
Examples of Wiring for Various Uses
8
Terminal Block
9
CC-Link/LT Master FX
3UC
(LT only)
10
Display module FX
3UC
(LT only)
2.1.2 FX2NC Series Input/output Extension Block
1. Connector type
• Installation: DIN rail of 35mm (1.38") in
width only
• Accessories:
1) FX
2NC-EX
FX
2NC-10BPCB1 power cable
2) Other models
None
2. Terminal type
• Installation: DIN rail of 35mm (1.38") in
width only
• Accessories:
1) FX
2NC-16EX-T
FX
2NC-10BPCB1 power cable
2) Other models
None
Type Model name W(mm)
MASS
(Weight)
A
FX
2NC-16EX
FX
2NC-16EYT
FX
2NC-16EX-DS
FX
2NC-16EYT-DSS
14.6
(0.58")
0.15
(0.33lbs)
B
FX
2NC-32EX
FX
2NC-32EYT
FX
2NC-32EX-DS
FX
2NC-32EYT-DSS
26.2
(1.04")
0.2
(0.44lbs)
Model name W(mm)
MASS
(Weight)
FX
2NC-16EX-T
FX
2NC-16EX-T-DS
20.2
(0.80")
0.15
(0.33lbs)
FX
2NC-16EYR-T
FX
2NC-16EYR-T-DS
24.2
(0.96")
0.2
(0.44lbs)
Unit:mm(inches)
A type
B type A, B type
74(2.92")
90(3.55")
90(3.55")
(power line)(power line)
W:26.2
(1.04")
W:14.6
(0.58")
13
(0.52")
(13
(0.52"))
(13
(0.52"))
90(3.55")
(power line)
Unit:mm(inches)
W
74(2.92")
15
(0.60")
(13
(0.52"))
