1.13.1 Re-examination of suitability for configuration
In this configuration, it is necessary to add the extension power supply unit FX3UC-1PS-5V due to the
restrictions in 5V DC power supply capacity and the restriction for the number of connectable units.
Construct the system as follows.
1. Components after countermeasures
Insert the extension power supply unit FX3UC-1PS-5V between the FX2NC-16EYR-T and the FX2NC-16EYR-
T.
2. Reexamination of system configuration availability
1) Restriction in the number of input/output points
There is no problem since the number of input/output points in the new system is "208".
2) Restriction for the 5V DC power supply capacity
The 5V DC power supply capacity is as follows after the countermeasures.
- Main unit side
- Extension power supply unit side
Terminating resistor
CL1X4-D1B2
4 points, input units
(Station No.1, Number
of occupied stations 1)
FX 3UC -
32MT-
LT
FX 2NC -
32EX
FX 2NC -
16EYR-T
FX 3UC -
1PS-5V
FX 2NC -
16EYR-T
FX 2NC -
4AD
FX 2NC -
CNV-IF
FX 2N -
10PG
FX 2N -
2LC
FX 2NC -
32EYT
FX 2N -
16EYT
FX 2NC -
32EX
Terminating resistor
CL1Y4-T1B2
4 points, output units
(Station No.2, Number
of occupied stations 1)
OK!!
a)Supplier side
FX 3UC -32MT-LT 350mA
b)Consumer side
FX 2NC -32EX
FX 2NC -16EYR-T
60mA
50mA
There is no problem since the total current consumption is less than the
capacity "350mA" supplied by the main unit.
120mA
"a)Supplier side" - "b)Consumer side" = 350mA - 270mA = 80mA
≥ 0mA
5V DC power supply capacity and current consumption
FX 2NC -32EX 60mA
FX 2NC -32EYT 100mA
220mA
270mA
OK!!
a)Supplier side
FX 3UC -1PS-5V 1A (1000mA)
b)Consumer side
FX 2NC -16EYR-T
FX 2NC -4AD
50mA
50mA
0mA
120mA
70mA
There is no problem since the total current consumption is less than the
capacity "1A (1000mA)" supplied by the extension power supply unit.
FX 2NC -CNV-IF
FX 2N -10PG
FX 2N -2LC
100mA
220mA
290mA
470mA
"a)Supplier side" - "b)Consumer side" = 1000mA - 470mA = 530mA
≥ 0mA
5V DC power supply capacity and current consumption
180mAFX 2N -16EYT
OK!!
