FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
1 Outline
1.4 List of Products
1
Outline
2
External Dimensions
3
Generic Specifications
4
Power Supply Specifications
5
Input Specifications
6
Output Specifications
7
Examples of Wiring for Various Uses
8
Terminal Block
9
CC-Link/LT Master FX
3UC
(LT only)
10
Display module FX
3UC
(LT only)
1.4.9 FX Series terminal blocks
*1. A power supply for the input circuit is required to connect a terminal block to the FX2N-16EX-C. The
current consumption at this time is as shown below. A power supply for the input circuit is not required
to connect a terminal block to the main unit or an input extension block for the FX
2NC.
*2. The applications shown below are not supported.
*3. The applications shown below are not supported.
Model name Input points Output points Function
Drive power
supply
FX-16E-TB
16 input points or
16 output points
To be directly connected to the PLC
input/output connector
*1
FX-32E-TB
32 input points,
32 output points or
16 input/output
points
FX-16EX-A1-TB
*2
16 - 100V AC input type *4
FX-16EYR-TB
*3
- 16 Relay output type 24V DC 80mA
FX-16EYT-TB
*3
- 16 Transistor output type (Sink output) 24V DC 112mA
FX-16EYT-H-TB
*3
- 16 Transistor output type (Sink output) 24V DC 112mA
FX-16EYS-TB
*3
- 16 Triac output type 24V DC 112mA
FX-16E-TB/UL
16 input points or
16 output points
To be directly connected to the PLC
input/output connector
Not required
FX-32E-TB/UL
32 input points,
32 output points or
16 input/output points
FX-16EYR-ES-TB/UL
*3
- 16 Relay output type 24V DC 80mA
FX-16EYT-ES-TB/UL
*3
- 16 Transistor output type (Sink output) 24V DC 112mA
FX-16EYT-ESS-TB/UL
*3
- 16 Transistor output type (Source output) 24V DC 112mA
FX-16EYS-ES-TB/UL
*3
- 16 Triac output type 24V DC 112mA
Power Supply Voltage Current Consumption
FX
3UC-MT/D, FX3UC-32MT-LT, FX2NC-EX,
FX
2NC-EYT, FX2NC-16EYT-C
Not required Not required
FX
2N-16EX-C 24V DC 112mA
Unsupported Applications
High-speed
processing
High-speed counter, input interruption, pulse catch, speed detection (SPD) instruction
Time division
input
Input matrix (MTR) instruction, hexadecimal input (HKY) instruction, digital switch (DSW)
instruction, arrow switch (ARWS) instruction
Other
Refresh and filter adjust (REFF) instruction, ten key input (TKY) instruction, absolute current
value read (ABS) instruction
Unsupported Applications
Pulse output
Pulse Y output (PLSY) instruction, acceleration/deceleration setup (PLSR) instruction, pulse
width modulation (PWM) instruction, DOG search zero return (DSZR) instruction, interruption
positioning (DVIT) instruction, batch data positioning mode (TBL) instruction, absolute current
value read (ABS) instruction, zero return (ZRN) instruction, variable speed pulse output (PLSV)
instruction, drive to increment (DRVI) instruction, drive to absolute (DRVA) instruction
Time division
input
Input matrix (MTR) instruction, hexadecimal input (HKY) instruction, digital switch (DSW)
instruction, arrow switch (ARWS) instruction
Time division
output
Seven segment with latch (SEGL) instruction, print (ASCII Code) (PR) instruction
