FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
C Operation of Special Devices (M8000 -, D8000 -)
C-3 Analog special adapters special devices
11
Memory Cassette/Battery
12
Test Run, Maintenance, Troubleshooting
A
Version Information
B
Performance Specifications
C
Special Devices (M8000 -,D8000 -)
D
Instruction List
E
Character-code
F
Discontinued models
Appendix C-3 Analog special adapters special devices
When analog special adapters are connected, operations and functions are assigned to the devices shown in
the tables below in accordance with the number of connected analog special adapters.
Devices which cannot be written are shaded in "Operation and function" column.
→ For details, refer to the manual of each product.
Appendix C-3-1 Special auxiliary relays (M8260 to M8299)
Number
Operation and function
FX3U-4AD-ADP FX3U-4DA-ADP FX3U-4AD-PT-ADP FX3U-4AD-TC-ADP
Compatible
Versions
Ver. 1.20 or later Ver. 1.20 or later Ver. 1.30 or later Ver. 1.30 or later
1st analog special adapter
M 8260
Input mode switching Ch1 Output mode switching Ch1 Temperature unit selection Temperature unit selection
M 8261 Input mode switching Ch2 Output mode switching Ch2 Not used Type-K/-J switching
M 8262 Input mode switching Ch3 Output mode switching Ch3 Not used Not used
M 8263
Input mode switching Ch4 Output mode switching Ch4 Not used Not used
M 8264
Not used Output hold mode cancel Ch1 Not used Not used
M 8265
Not used Output hold mode cancel Ch2 Not used Not used
M 8266
Not used Output hold mode cancel Ch3 Not used Not used
M 8267
Not used Output hold mode cancel Ch4 Not used Not used
M 8268
Not used Not used Not used Not used
M 8269
Not used Not used Not used Not used
2nd analog special adapter
M 8270
Input mode switching Ch1 Output mode switching Ch1 Temperature unit selection Temperature unit selection
M 8271 Input mode switching Ch2 Output mode switching Ch2 Not used Type-K/-J switching
M 8272 Input mode switching Ch3 Output mode switching Ch3 Not used Not used
M 8273
Input mode switching Ch4 Output mode switching Ch4 Not used Not used
M 8274
Not used Output hold mode cancel Ch1 Not used Not used
M 8275
Not used Output hold mode cancel Ch2 Not used Not used
M 8276
Not used Output hold mode cancel Ch3 Not used Not used
M 8277
Not used Output hold mode cancel Ch4 Not used Not used
M 8278
Not used Not used Not used Not used
M 8279
Not used Not used Not used Not used
3rd analog special adapter
M 8280
Input mode switching Ch1 Output mode switching Ch1 Temperature unit selection Temperature unit selection
M 8281 Input mode switching Ch2 Output mode switching Ch2 Not used Type-K/-J switching
M 8282 Input mode switching Ch3 Output mode switching Ch3 Not used Not used
M 8283
Input mode switching Ch4 Output mode switching Ch4 Not used Not used
M 8284
Not used Output hold mode cancel Ch1 Not used Not used
M 8285
Not used Output hold mode cancel Ch2 Not used Not used
M 8286
Not used Output hold mode cancel Ch3 Not used Not used
M 8287
Not used Output hold mode cancel Ch4 Not used Not used
M 8288
Not used Not used Not used Not used
M 8289
Not used Not used Not used Not used
4th analog special adapter
M 8290
Input mode switching Ch1 Output mode switching Ch1 Temperature unit selection Temperature unit selection
M 8291 Input mode switching Ch2 Output mode switching Ch2 Not used Type-K/-J switching
M 8292 Input mode switching Ch3 Output mode switching Ch3 Not used Not used
M 8293
Input mode switching Ch4 Output mode switching Ch4 Not used Not used
M 8294
Not used Output hold mode cancel Ch1 Not used Not used
M 8295
Not used Output hold mode cancel Ch2 Not used Not used
M 8296
Not used Output hold mode cancel Ch3 Not used Not used
M 8297
Not used Output hold mode cancel Ch4 Not used Not used
M 8298
Not used Not used Not used Not used
M 8299
Not used Not used Not used Not used
