FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
1 Outline
1.4 List of Products
1.4.3 Special function units/blocks
For details on each product, refer to the appropriate product manual.
1. Analog control
a) FX2NC/FX3UC Series
b) FX
0N/FX2N/FX3U Series
When connected to the special function blocks of the following table, the FX
2NC-CNV-IF or FX3UC-
1PS-5V is required.
Model name
Input Output
Connecting
type
Number
of input/
output
points
5V DC current
consumption
(mA)
Points Type Points Type
FX
0N-16EYR - - 16 Relay
Terminal
block
16 40
FX
2N-16EYT - - 16
Transistor
(sink)
Terminal
block
16 180
FX
2N-16EYT-ESS/UL - - 16
Transistor
(source)
Terminal
block
16 180
FX
0N-16EYT - - 16
Transistor
(sink)
Terminal
block
16 40
FX
2N-16EYT-C - - 16 Connector 16 180
FX
2N-16EYS - - 16 Triac
Terminal
block
16 160
Model name Description
Number
of input/
output
points
5V DC current
consumption
(mA)
FX
2NC-4AD 4-ch Voltage/current input 8 50
FX
2NC-4DA 4-ch Voltage/current output 8 30
FX
3UC-4AD 4-ch Voltage/current input 8 100
Model name Description
Number
of input/
output
points
5V DC current
consumption
(mA)
FX
2N-2AD 2-ch Voltage/current input 8 20
FX
2N-4AD 4-ch Voltage/current input 8 30
FX
2N-8AD
8-ch Voltage/current/temperature
(thermocouple) input
850
FX
2N-4AD-PT
4-ch Temperature
(resistance thermometer sensor) input
830
FX
2N-4AD-TC 4-ch Temperature (thermocouple) input 8 30
FX
2N-2DA 2-ch Voltage/current output 8 30
FX
2N-4DA 4-ch Voltage/current output 8 30
FX
0N-3A
2-ch Voltage/current input
1-ch Voltage/current output
830
FX
2N-5A
4-ch Voltage/current input
1-ch Voltage/current output
870
FX
2N-2LC
2 loops Temperature control
(resistance thermometer sensor/thermocouple)
870
FX
3U-4AD 4-ch Voltage/current input 8 110
FX
3U-4DA 4-ch Voltage/current output 8 120
C
D
E
