41
FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
1 Outline
1.4 List of Products
1
Outline
2
External
Dimensions
3
Generic
Specifications
4
Power Supply
Specifications
5
Input
Specifications
6
Output
Specifications
7
Examples of
Wiring for
Various Uses
8
Terminal Block
9
CC-Link/LT
Master FX
3UC
(LT only)
10
Display module
FX
3UC
(LT only)
1.4.4 Expansion boards
1. Communication functions
*1. Add the current consumption shown below only when the following equipment is connected to the
FX
3U
-422-BD.
1.4.5 Special adapters
1. Analog functions
2. Communication functions
Model name Description
Number
of input/
output
points
5V DC current
consumption
(mA)
FX
3U-CNV-BD Conversion of connector for fitting special adapter 0 -
FX
3U-232-BD For RS-232C communication 0 20
FX
3U-422-BD
For RS-422 communication
(having the same function as that of the peripheral device
connector incorporated in the main unit)
0
20
*1
FX3U-485-BD For RS-485 communication 0 40
FX
3U-USB-BD
For USB communication
(for programming from a personal computer)
015
Connection model
name
5V DC current
consumption
(mA)
Application
FX-20P(-E)(-SET0)
150
*2
Handy programming panel
*2. When the FX-20P-RWM is used, the current is 180mA.
FX-10P(-E)(-SET0) 120
FX-232AW/FX-232AWC 220
RS-232C/RS-422 converter
FX-232AWC-H 120
FX-USB-AW 15 USB/RS-422 converter (USB side : 30mA)
FX-10DM(-E)(-SET0) 220 Display module
F920GOT-BBD5-K(-E) 220 Graphic operation terminal
Model name Description
Number
of input/
output
points
5V DC current
consumption
(mA)
FX
3U-4AD-ADP 4-ch Voltage/current input 0 15
FX
3U-4DA-ADP 4-ch Voltage/current output 0 15
FX
3U-4AD-PT-ADP
4-ch Temperature
(platinum resistance thermometer sensor) input
015
FX
3U-4AD-TC-ADP 4-ch Temperature (thermocouple) input 0 15
Model name Description
Number
of input/
output
points
5V DC current
consumption
(mA)
FX
3U-232ADP(-MB) RS-232C communication 0 30
FX
3U-485ADP(-MB) RS-485 communication 0 20
I
J
J
To Next Page
