FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
1 Outline
1.4 List of Products
*4. A power supply for the input circuit is required when connected to the FX2N-16EX-C.
The current consumption is shown in the table below.
1.4.10 Input/output cable • Input/output connector • Power cable
1.4.11 Power supply unit
1.4.12 Programming tool
The following programming tool supports FX3UC Series PLCs.
For inapplicable programming tools and versions, refer to Appendix A-2-2.
Power Supply Voltage Current Consumption
FX
3UC-MT/D, FX3UC-32MT-LT, FX2NC-EX 24V DC 48mA
FX
2N-16EX-C 24V DC 160mA
Classification Model name Description
Input/output
cables
FX-16E-500CAB-S 5m(16’4") Bulk wire
FX-16E-150CAB 1.5m(4’11")
Flat cable (with tube). Both ends are provided with 20-pin
connectors.
FX-16E-300CAB 3m(9’10")
FX-16E-500CAB 5m(16’4")
FX-16E-150CAB-R 1.5m(4’11")
Round multicore cable. Both ends are provided with 20-pin
connectors.
FX-16E-300CAB-R 3m(9’10")
FX-16E-500CAB-R 5m(16’4")
FX-A32E-150CAB 1.5m(4’11") Flat cable (with tube). The end on the PLC side is provided
with two 20-pin connectors, and the end on the terminal block
side is provided with an exclusive connector. 1 common
terminal for 32 input/output points
FX-A32E-300CAB 3m(9’10")
FX-A32E-500CAB 5m(16’4")
Input/output
connector
FX
2C-I/O-CON 10-piece set Input/output connector for flat cable
FX
2C-I/O-CON-S 5-piece set
Input/output connector for bulk wire for 0.3 mm
2
[AGW22]
FX
2C-I/O-CON-SA 5-piece set
Input/output connector for bulk wire for 0.5 mm
2
[AGW20]
Power cable
FX
2NC-100MPCB 1m (3'3") Power cable for main unit
FX
2NC-100BPCB 1m (3'3") Input power cable for FX2NC series input extension blocks
FX
2NC-10BPCB1 0.1m(0'3")
Input power crossover cable for FX
2NC series input extension
blocks
Model name Description Drive power supply Current Capacity DC
FX
2N-20PSU 24V DC power supply 100V AC to 240V AC 24V DC 2A
Model name Description
GX Developer
Version 8.13P or later of SWD5C-GPPW-J and SWD5C-GPPW-E supports FX
3UC.
Although versions prior to 8.13P can be used for programming by selecting FX2N(C),
restrictions apply.
For details, refer to Appendix A-2-2.
