FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
A Version Information and Peripheral Equipment Connect ability
A-1 Version Upgrade History
11
Memory Cassette/Battery
12
Test Run, Maintenance, Troubleshooting
A
Version Information
B
Performance Specifications
C
Special Devices (M8000 -,D8000 -)
D
Instruction List
E
Character-code
F
Discontinued models
Appendix A-1-3 Version upgrade history
FX3UC Series performed the following upgrade.
*1. The FX
3UC-32MT-LT supports Ver.2.41 from the manufacturer's serial number "7X****" (October
2007).
Version
Manufacturer's serial
number
Contents of version upgrade
Ver.1.00 41
**** (January, 2004) FX3UC-32MT-LT (First product)
Ver.1.20 44**** (April
, 2004)
Supports connection of following special analog adapters
-FX3U-4AD-ADP
-FX
3U-4DA-ADP
Ver.1.30 48**** (August
, 2004)
• Supports connection of following special analog adapters
-FX
3U-4AD-PT-ADP
-FX
3U-4AD-TC-ADP
• Supports connection of following special function block
-FX
3UC-4AD
• Adding the following instructions and function upgrade
- Adding SCL2 (FNC269) instruction
- Adding RWER (FNC294) instruction
- Adding INITER (FNC295) instruction
- Function upgrade of DVIT (FNC151) instruction
Ver.2.20 55**** (May, 2005)
• Supports following 28 instructions
ZPUSH (FNC102), ZPOP (FNC103), WSUM (FNC140),
WTOB (FNC141), BTOW (FNC142), UNI (FNC143),
DIS (FNC144), SORT2 (FNC149), TBL (FNC152),
COMRD (FNC182), DUTY (FNC186), BK + (FNC192),
BK (FNC193), BKCMP = (FNC194),
BKCMP > (FNC195), BKCMP < (FNC196),
BKCMP<> (FNC197), BKCMP
<= (FNC198),
BKCMP
>= (FNC199), STR(FNC200),
VAL (FNC201), INSTR (FNC208), FDEL (FNC210),
FINS (FNC211), DABIN (FNC260), BINDA (FNC261),
RBFM (FNC278), WBFM (FNC279)
• Adds function of following 5 instructions
SPD (FNC56), DSZR (FNC150), DVIT (FNC151),
ZRN (FNC156), PLSV (FNC157), HCMOV (FNC189)
• Supports connection of FREQROL-F700/A700 inverters
supporting following 5 instructions
IVCK (FNC270), IVDR (FNC271), IVRD (FNC272),
IVWR (FNC273), IVBWR (FNC274)
• Adds second entry code
(when GX Developer SW8.23Z (Ver. 8.23Z or later) is used).
• Supports BFM initial value setting function
(when GX Developer SW8.23Z (Ver. 8.23Z or later) is used).
• Mitigates restriction in writing during RUN
(when GX Developer SW8.23Z (Ver. 8.23Z or later) is used).
- Number of steps which can be changed by one-time write
during RUN is changed.
127 steps → 256 steps
- Handling of circuit blocks which can be changed by one-
time write during RUN is changed.
Program of continuous circuit blocks having 127 steps or
less
→Program of circuit blocks having 256 steps or less in total
Ver.2.30 5Y**** (November, 2005)
The following instructions are added or their functions are
enhanced:
MEP and MEF instructions are added.
The functions of the MUL (FNC 22), DIV (FNC 23) and RS2 (FNC
87) instructions are enhanced.
Ver.2.41
79****
*1
(September, 2007)
FX
3UC-MT/D, DSS (First product)
