1.11 Number of occupied I/O points and 5V DC current consumption
The table below shows the number of input/output occupied points for each model and the current consumed
from the 5V DC main unit built-in power supply or the 5V DC FX
3UC-1PS-5V power supply unit.
1. Main units
2. Special adapters
3. Expansion boards
*1. When the FX3U-422-BD is connected, add the current consumed by the GOT/programming tool
.
Division Model name
Number of input/
output points
5V DC current
consumption (mA)
FX
3UC-16MT/D 16 -
FX
3UC-16MT/DSS 16 -
FX
3UC-32MT/D 32 -
FX
3UC-32MT/DSS 32 -
FX
3UC-32MT-LT 32 -
FX
3UC-64MT/D 64 -
FX
3UC-64MT/DSS 64 -
FX
3UC-96MT/D 96 -
FX
3UC-96MT/DSS 96 -
Division Model name
Number of input/
output points
5V DC current
consumption (mA)
FX
3U-4AD-ADP 0 15
FX
3U-4DA-ADP 0 15
FX
3U-4AD-PT-ADP 0 15
FX
3U-4AD-TC-ADP 0 15
FX
3U-232ADP(-MB) 0 30
FX
3U-485ADP(-MB) 0 20
Division Model name
Number of input/
output points
5V DC current
consumption (mA)
FX
3U-232-BD 0 20
FX
3U-422-BD 0
20
*1
FX3U-485-BD 0 40
FX
3U-USB-BD 0 15
FX
3U-CNV-BD 0 -
A
A1
B
B1
B2
B
B3
F
