FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
2 External Dimensions and Terminal Arrangement
2.1 External Dimensions (MASS/Installation/Accessories)
2.1.3 FX2N Series Input/output Extension Block
1. Connector / Terminal type
• Installation: DIN rail of 35 mm (1.38") in
width or screws
• Accessories: Label for indication of I/O
number,
• Terminal block: M3 screws
• The extension cable is already connected to
the extension block
Type Model name W(mm)
MASS
(Weight)
A
FX
2N-8ER
FX
2N-8EX
FX
2N-8EX-UA1/UL
FX
2N-8EYR
FX
2N-8EYT
FX
2N-8EYT-H
FX
2N-8ER-ES/UL
FX
2N-8EX-ES/UL
FX
2N-8EYR-ES/UL
FX
2N-8EYT-ESS/UL
43
(1.70")
0.2
(0.44lbs)
B
FX
2N-16EX
FX
2N-16EX-C
FX
2N-16EXL-C
FX
2N-16EYR
FX
2N-16EYT
FX
2N-16EYT-C
FX
2N-16EYS
FX
2N-16EX-ES/UL
FX
2N-16EYR-ES/UL
FX
2N-16EYT-ESS/UL
40
(1.58")
0.3
(0.66lbs)
IN
FX2N-8EX
POWER
0 1 23
7654
A type
Unit:mm(inches)
87(3.43")
W:40(1.58")
B type
Unit:mm(inches)
4(0.16")
W:43(1.70")
80(3.15")
(mounting hole pitch)
90(3.55")
2-φ4.5 mounting holes
87(3.43")
9(0.36")
2-φ4.5 mounting holes
80(3.15")
(mounting hole pitch)
90(3.55")
9(0.36")
