FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
10 Display Module (Only FX3UC-32MT-LT)
10.9 Contrast
10.9 Contrast
The liquid crystal display contrast setting is specified at the "Contrast" menu. Selections made at this menu
are saved at D8302. A contrast setting of "0" is specified at factory default.
1) At the menu screen, use the [+]/[-] buttons to move the cursor to the
"Contrast" item, then press [OK] to display the "contrast adjustment
screen".
To cancel the operation and return to the "Main unit I/O operation
display", press [ESC].
2) Use the [+]/[-] buttons to adjust the contrast.
To cancel the operation and return to the "menu screen", press
[ESC].
3) Press the [OK] button to register the selected setting and return to the "menu screen".
Button Operation Description
ESC Cancels the operation and returns to the "menu screen".
-
Lowers the contrast
(decreases the numeric value. The value can be decreased to -5.)
+
Increases the contrast
(increases the numeric value. The value can be increased to +10.)
OK Registers the selected setting and returns to the "menu screen".
Ctnora
(5-
0
10 )~
st
(5-
3
10 )~
Ctnorast
To Next Page
