10.10 Clock Menu (Current Time Setting)
The "ClockMenu" menu consists of "current time display" and the "time setting" items.
The current time should be set before operating the system.
10.10.1 Current time setting procedure
1) At the menu screen, use the [+]/[-] buttons to move the cursor to the
"ClockMenu" item, then press [OK] to display the selection screen
shown at right.
To cancel the operation and return to the "Main unit I/O operation
display", press [ESC].
2) Use the [+]/[-] buttons to move the cursor to the "Clock setting" item.
To cancel the operation and return to the "menu screen", press
[ESC].
3) Press the [OK] button to display the "Clock setting screen".
To cancel the operation and return to the "selection screen", press
[ESC].
4) Use the [+]/[-] buttons to change the blinking data as desired, then
press [OK] to register the change.
Settings are performed in the following sequence: Year → Month →
Day → Hours → Minutes → Seconds.
After pressing [OK] to register the final "seconds" setting, a "Current
time is set" message is displayed, completing the current time
setting procedure.
5) Press [OK] or [ESC] to return to the "selection screen".
6) Press [ESC] to return to the "menu screen".
Button Operation Description
ESC
Returns to the previous setting item.
Returns to the "selection screen", when at the "Year"
item ("Year" is blinking) position.
-
Reduces the value.
Hold for 1 second or longer for high-speed reduction.
+
Increases the value.
Hold for 1 second or longer for high-speed increase.
OK
Proceeds to the next setting item.
"Current time is set" message displays if pressed at the
"Seconds" item ("Seconds" is blinking).
Crruentt emi
tCcolkset gni
Crruentt emi
tCcolkset gni
19 . 8 . 19
7:11:19[ u]Th
93 *
tCcolkset gni
The default "Year" display is a
2-digit value indicating the
Western calendar year.
tCcolkset gni
31 . 1 . 20
3:59:59[ t ]Sa
04
2
*
*
Crruentt emi
tCcolkset gni
