FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
B Performance Specifications
*1. FX3UC-32MT-LT becomes 240 points.
*2. FX
3UC-32MT-LT becomes X000 to X357, and Y000 to Y357.
Item Performance
Processing
speed
Basic instructions 0.065 µs/instruction
Applied instructions 0.642 µs to several hundred µs/instruction
Number of
input/output
points
Ver.2.20 or later
(1)Extension combined
number of input points
248 points
*1
(3)
Total number of
points
(1) + (2) ≤ (3) total number of points
is 256 or less.
(2)Extension combined
number of output
points
248 points
*1
(4)Remote I/O number
of points (CC-Link)
224 points or less
Either the CC-Link or AS-i master
can be used (the two cannot be used
concurrently)
(4)Remote I/O number
of points (AS-i)
248 points or less
(3) + (4) total number of
points
384 points or less
Former than Ver. 2.20
Extension combined
number of input points
240 points
The device numbers are octal.
Extension combined
number of output
points
240 points
Extension combined
total number of points
256 points
Input/output
relay
Input relay
X000 to X367
*2
248 points
*1
The device numbers are octal.
The total number of input and output
points is 256.
Output relay
Y000 to Y367
*2
248 points
*1
Auxiliary relay
For general
[changeable]
M0 to M499 500 points
The retentive status can be changed
by parameter settings.
For keeping
[changeable]
M500 to M1023 524 points
For keeping
[fixed]
M1024 to
M7679
6656 points -
For special
M8000 to
M8511
512 points -
State
Initial state
(for general)
S0 to S9 10 points
The retentive status can be changed
by parameter settings.
For general
[changeable]
S10 to S499 490 points
For keeping
[changeable]
S500 to S899 400 points
For annunciator S900 to S999 100 points
For keeping
[fixed]
S1000 to S4095 3096 points
Timer (on-
delay timer)
100 ms T0 to T191 192 points 0.1 to 3,276.7 sec
100 ms
[for subroutine/
interruption
subroutine]
T192 to T199 8 points 0.1 to 3,276.7 sec
10 ms T200 to T245 46 points 0.01 to 327.67 sec
1 ms accumulating
type
T246 to T249 4 points 0.001 to 32.767 sec
100 ms accumulating
type
T250 to T255 6 points 0.1 to 3,276.7 sec
1 ms T256 to T511 256 points 0.001 to 32.767 sec
