RL78/G15 CHAPTER 4 PORT FUNCTIONS

R01UH0959EJ0110 Rev.1.10 Page 101 of 765

Mar 7, 2023

Table 4-4. Pm, PMn, PUp, POMq, PMCr Registers and the Bits (16-pin Products)

Port Bit name

Pm register PMn register PUp register POMq register PMCr register

PORT0 0 P00 PM00 PU00 POM00 —

1 P01 PM01 PU01 POM01 PMC01

2 P02 PM02 PU02 — PMC02

3 P03 PM03 PU03 POM03 PMC03

4 P04 PM04 PU04 POM04 PMC04

5 P05 PM05 PU05 POM05 PMC05

6 P06 PM06 PU06 POM06 PMC06

7 P07 PM07 PU07 POM07 PMC07

PORT4 0 P40 PM40 PU40 — —

1 P41 PM41 PU41 — —

PORT12 1 P121 PM121 PU121 — —

2 P122 PM122 PU122 — —

5 P125 PM125 PU125 — —

PORT13 7 P137 — — — —
