Renesas RL78/G15 User Manual

RL78/G15 CHAPTER 6 TIMER ARRAY UNIT
R01UH0959EJ0110 Rev.1.10 Page 205 of 765
Mar 7, 2023
6.5 Operation of Counter
6.5.1 Count clock (f
TCLK
)
The count clock (f
TCLK
) of the timer array unit can be selected between the following by CCSmn bit of timer mode register
mn (TMRmn).
●
Operation clock (f
MCK
) specified by the CKSmn0 and CKSmn1 bits
●
Valid edge of input signal input from the TImn pin
Because the timer array unit is designed to operate in synchronization with f
CLK
, the timings of the count clock (f
TCLK
) are
shown below.
(1) When operation clock (f
MCK
) specified by the CKSmn0 and CKSmn1 bits is selected (CCSmn = 0)
The count clock (f
TCLK
) is between f
CLK
to f
CLK
/2
15
by setting of timer clock select register m (TPSm). When a divided f
CLK
is selected, however, the clock selected in TPSmn register, but a signal which becomes high level for one period of f
CLK
from its rising edge. When a f
CLK
is selected, fixed to high level.
Counting of timer count register mn (TCRmn) delayed by one period of f
CLK
from rising edge of the count clock, because
of synchronization with f
CLK
. But, this is described as “counting at rising edge of the count clock”, as a matter of
convenience.
Figure 6-22. Timing of f
CLK
and count clock (f
TCLK
) (When CCSmn = 0)
f
CLK
f
CLK
/2
f
CLK
/
4
f
CLK
/
8
f
CLK
/16
f
TCLK
(= f
MCK
=
CKmn)
•
•
•
•
•
•
•
•
Remark 1. : Rising edge of the count clock
: Synchronization, increment/decrement of counter
Remark 2. f
CLK
: CPU/peripheral hardware clock
