RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 362 of 765

Mar 7, 2023

CHAPTER 12 SERIAL ARRAY UNIT

A single serial array unit has up to two serial channels. Each channel can achieve 3-wire serial (simplified SPI or

CSI

Note 1

), UART, and simplified I

C communication.

Function assignment of each channel supported by the RL78/G15 is as shown below.

Note 1. Although the CSI function is generally called SPI, it is also called CSI in this product, so it is referred to as

such in this manual.

 10- and 8-pin products

Unit Channel Used as Simplified SPI (CSI) Used as UART Used as Simplified I

0 0 CSI00 UART0 IIC00

1 — —

 20- and 16-pin products

Unit Channel Used as Simplified SPI (CSI) Used as UART Used as Simplified I

0 0 CSI00 UART0 IIC00

1 CSI01 IIC01

Caution Most of the following descriptions in this section use the units and channels of the 20-pin products as

an example.
