RL78/G15 CHAPTER 5 CLOCK GENERATOR
R01UH0959EJ0110 Rev.1.10 Page 153 of 765
Mar 7, 2023
5.6.2 Example of setting X1 oscillation clock
After a reset release, the CPU/peripheral hardware clock (f
CLK
) always starts operating with the high-speed on-chip
oscillator clock. To subsequently change the clock to the X1 clock, set the oscillator and start oscillation by using the
oscillation stabilization time select register (OSTS), clock operation mode control register (CMC), and clock operation
status control register (CSC) and wait for oscillation to stabilize by using the oscillation stabilization time counter status
register (OSTC). After the oscillation stabilizes, set the X1 clock to f
CLK
by using the system clock control register (CKC).
[Register settings] Set the register in the order of <1> to <5> below.
<1> Set (1) the OSCSEL bit of the CMC register, except for the cases where f
X
> 10 MHz, in such cases set (1) the
AMPH bit, to operate the X1 oscillator.
7 6 5 4 3 2 1 0
CMC
EXCLK
0
OSCSEL
1
0
0
0
0
0
AMPH
0/1
AMPH bit: Set this bit to 0 if the X1 clock is 10 MHz or less.
<2> Using the OSTS register, select the oscillation stabilization time of the X1 oscillator at releasing of the STOP
mode.
Example: Setting values when a wait of at least 104 µs is set based on a 10 MHz resonator.
7 6 5 4 3 2 1 0
OSTS
0
0
0
0
0
OSTS2
0
OSTS1
1
OSTS0
0
<3> Clear (0) the MSTOP bit of the CSC register to start oscillating the X1 oscillator.
7 6 5 4 3 2 1 0
CSC
MSTOP
0
0
0
0
0
0
0
HIOSTOP
0
<4> Use the OSTC register to wait for oscillation of the X1 oscillator to stabilize.
Example: Wait until the bits reach the following values when a wait of at least 104 µs is set based on a 10 MHz
resonator.
7 6 5 4 3 2 1 0
OSTC
MOST8
1
MOST9
1
MOST10
1
MOST11
0
MOST13
0
MOST15
0
MOST17
0
MOST18
0
<5> Use the MCM0 bit of the CKC register to specify the X1 clock as the CPU/peripheral hardware clock.
7 6 5 4 3 2 1 0
CKC
0
0
MCS
0
MCM0
1
0
0
0
0
