RL78/G15 CHAPTER 20 ON-CHIP DEBUG FUNCTION

R01UH0959EJ0110 Rev.1.10 Page 686 of 765

Mar 7, 2023

20.3 On-Chip Debug Security ID

The RL78 microcontroller has an on-chip debug operation control bit in the flash memory at 000C3H (see CHAPTER 18

OPTION BYTE) and an on-chip debug security ID setting area at 000C4H to 000CDH, to prevent third parties from

reading memory content.

Table 20-1. On-Chip Debug Security ID

Address On-Chip Debug Security ID

000C4H to 000CDH Any ID code of 10 bytes
