RL78/G15 CHAPTER 19 FLASH MEMORY

R01UH0959EJ0110 Rev.1.10 Page 668 of 765

Mar 7, 2023

19.5 Processing Time for Each Command When PG-FP5 Is in Use

(Reference Values)

The following tables show the processing time for each command (reference value) when PG-FP5 is used as a

dedicated flash memory programmer.

Table 19-8. Processing Time for Each Command When PG-FP5 Is in Use (Reference Values)

Command of PG-FP5 Code Flash Data Flash

4 KB 8 KB 1 KB

R5F12067xSP,

R5F12047xNA,

R5F12047xSP,

R5F12017xSP,

R5F12007xNS

(x = M,G,A)

R5F12068xSP,

R5F12048xNA,

R5F12048xSP,

R5F12018xSP,

R5F12008xNS

(x = M,G,A)

All products

Write after erase 1.5 s 2.0 s 1.0 s

CRC check 0.5 s 1.0 s 0.5 s

Remark The command processing times (reference values) shown in the table are typical values under the following

conditions.

Port: TOOL0 (single-line UART)

Speed: 115,200 bps
