RL78/G15 CHAPTER 8 CLOCK OUTPUT/BUZZER OUTPUT CONTROLLER
R01UH0959EJ0110 Rev.1.10 Page 307 of 765
Mar 7, 2023
8.2 Configuration of Clock Output/Buzzer Output Controller
The clock output/buzzer output controller includes the following hardware.
Table 8-1. Configuration of Clock Output/Buzzer Output Controller
Item Configuration
Control registers Clock output select register 0 (CKS0)
Port mode registers 0, 4 (PM0, PM4)
Port registers 0, 4 (P0, P4)
Port mode control register 0 (PMC0)
Peripheral I/O redirection register 3 (PIOR3)
8.3 Registers Controlling Clock Output/Buzzer Output Controller
The following registers are used to control the clock output/buzzer output controller.
●
Clock output select register 0 (CKS0)
●
Port mode registers 0, 4 (PM0, PM4)
●
Port mode control register 0 (PMC0)
●
Peripheral I/O redirection register 3 (PIOR3)
