RL78/G15 CHAPTER 5 CLOCK GENERATOR
R01UH0959EJ0110 Rev.1.10 Page 131 of 765
Mar 7, 2023
5.2 Configuration of Clock Generator
The clock generator includes the following hardware.
Table 5-1. Configuration of Clock Generator
Item Configuration
8-pin
products
10-pin
products
16-pin
products
20-pin
products
Control registers Clock operation mode control register (CMC) — —  
System clock control register (CKC) — —  
Clock operation status control register (CSC) — —  
Oscillation stabilization time counter status register
(OSTC)
— —  
Oscillation stabilization time select register (OSTS) — —  
Peripheral enable register 0 (PER0)    
Operation speed mode control register (OSMC)    
High-speed on-chip oscillator frequency select
register (HOCODIV)
   
High-speed on-chip oscillator trimming register
(HIOTRM)
   
Oscillators X1 oscillator — —  
High-speed on-chip oscillator    
Low-speed on-chip oscillator    
Remark : Provided, —: Not provided
