CHAPTER 2 PIN FUNCTIONS
2.1 Port Function
The input or output, buffer, and pull-up resistor settings on each port are also valid for the alternate functions.
2.1.1 8-pin products
Function
Name
Pin Type I/O
After Reset
Release
Alternate Function Function
P01 7-3-2 I/O Analog input
TOOLRxD/ANI0/INTP5/TI02/
TO02/SI00/RxD0/SDA00/
SDAA0
Port 0.
3-bit I/O port.
Input/output can be specified in 1-bit units.
Use of an on-chip pull-up resistor can be
specified by a software setting at input port.
Output of P01 and P03 can be set to N-ch
open-drain output (V
DD
tolerance).
P01, P03, and P04 can be set to analog
input
Note 1
.
P03 7-9-2
TOOLTxD/ANI2/IVCMP0/
INTP4/TO00/SO00/TxD0/
SCLA0/(TI00)
P04
ANI3/IVREF0/INTP3/TI01/
TO01/SCK00/SCL00
P40 7-1-1 I/O Input port
TOOL0/PCLBUZ0/VCOUT0/
INTP2/(TI01/TO01)
Port 4.
1-bit I/O port.
Input/output can be specified in 1-bit units.
Use of an on-chip pull-up resistor can be
specified by a software setting at input port.
P125 3-2-1 I/O Input port RESET
¯¯¯¯¯¯
/INTP1/(VCOUT0) Port 12.
1-bit I/O port.
Use of an on-chip pull-up resistor can be
specified by a software setting.
P125 is also used for the input pin for external
reset (RESET
¯¯¯¯¯¯
).
To use the pin for external reset, set the
PORTSELB bit in the option byte (000C1H) to
1.
P137 2-1-2 Input Input port INTP0/TI00 Port 13.
1-bit input only port.
Note 1. Setting digital or analog to each pin can be done in the port mode control register 0 (PMC0) (can be set in 1-
bit units).
Remark Functions in parentheses can be assigned via settings in the peripheral I/O redirection registers 0 to 3
(PIOR0 to PIOR3). Refer to Figure 4-6 Format of Peripheral I/O Redirection Registers 0 to 3 (PIOR0 to
PIOR3).
