RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 459 of 765

Mar 7, 2023

UART0 uses channels 0 and 1 of SAU0.

 10- and 8-pin products

Unit Channel Used as simplified SPI (CSI) Used as UART Used as Simplified I

0 0 CSI00 UART0 IIC00

1 — —

 20- and 16-pin products

Unit Channel Used as simplified SPI (CSI) Used as UART Used as Simplified I

0 0 CSI00 UART0 IIC00

1 CSI01 IIC01

Select any function for each channel. Only the selected function is possible. If UART0 is selected for channels 0 and 1 of

unit 0, for example, these channels cannot be used for CSI00 and CSI01

Caution When using a serial array unit for UART, both the transmitter side (even-numbered channel) and the

receiver side (odd-numbered channel) can only be used for UART.

UART performs the following two types of communication operations.

●

UART transmission (See 12.6.1)

●

UART reception (See 12.6.2)
