Rockwell Automation Publication 2711P-UM008I-EN-P - February 2022 165
Chapter 5
Device Info Menu
The Device Info menu displays name, network, and version information about
your PanelView terminal.
Table 36 - Device Info
Field Description
Network Information If the network cable is not plugged in, there is no information displayed here. If a
network cable is plugged in, the following information is shown:
• IPv4—Displays the IPv4 address currently assigned to the terminal.
• Status—Displays the type of access available. Displays Local network access
only or Local and Internet access, depending on the internet access availability.
Device Name Displays the name of the device given by the user. This can be set-up on the out of
box first power up or in ME Station - Terminal Settings > Networks and
Communications > Network Connections > Device Name.
Network Displays Ethernet if connected to a network. If no connection is identified, it
displays No Internet Connection.
IP Address Displays the IP address currently assigned to the terminal. If the network cable is
not plugged in, the IP Address displays as 0.0.0.0
OS Version Displays the Microsoft Windows 10 IoT Core OS version.
Platform Version Displays the version of bundled firmware from Rockwell Automation. The more…
button displays a page that shows versions of additional components.
Copyright Info Displays the copyright year of the terminal. The more… button displays a
complete copyright page.
Bootloader Version Displays the version of Bootloader that is loaded on the terminal.
DLR Network Switch
Version
Displays the firmware version of the Device Level Ring Network Switch.
Connected Devices Displays the device name of any connected USB devices.
