Rockwell Automation Publication 2711P-UM008I-EN-P - February 2022 227
Appendix A
Fonts Resident on Terminal
True Type Fonts
The table lists TrueType fonts that are pre-installed on the terminals. The
default system font is Tahoma.
On Series A terminals, you can load additional fonts on the system by copying
the font files to the \Windows\Fonts folder on the terminal desktop. To access
this folder, open the My Device icon on the terminal desktop or choose
Start>Programs>Windows Explorer.
TIP The Arial Unicode MS font contains almost 50,000 characters and provides
default language support for many non-Latin languages and scripts
including Arabic, Hebrew, Vietnamese, Thai, Hindi (Devanagari), and other
Indic languages. The font also includes Chinese, Japanese, and Korean (CJK)
support.
IMPORTANT OpenType fonts (.otf) can contain many extra symbols and characters and
can have large files sizes. If you install OpenType fonts, it can result in a
reduction in available memory for applications. We recommend that you
install only TrueType fonts. If you need an OpenType font, install only the
font family that you want to use.
Table 56 - TrueType Fonts (.ttf and .ttc)
Font Type Font Name File Name
Latin Fonts Arial Unicode MS version 1.01 arialuni.ttf
Arial
Arial (Subset 1_30) arial_1_30.ttf
Arial Black arialk.ttf
Arial Bold arialbd.ttf
Arial Bold Italic arialbi.ttf
Arial Italic ariali.ttf
Comic Sans MS
Comic Sans MS comic.ttf
Comic Sans MS Bold comicbd.ttf
Courier New
Courier New (Subset 1_30) cour_1_30.ttf
Courier New Bold courbd.ttf
Courier New Bold Italic courbi.ttf
Courier New Italic couri.ttf
