Rockwell Automation Publication 2711P-UM008I-EN-P - February 2022 213
Chapter 7
Update DLR Network Switch
Firmware (Series B Terminals
Only)
(1)
The DLR Network Switch Firmware Update is new for Series B terminals
(Series C for Stainless Steel terminals). This firmware is for the DLR
functionality of the terminal and is separate from the System Firmware update.
If the DLR functionality changes in the future, the update must be done using
this process. If there is an update available, the .dmk file would be posted on the
Product Compatibility and Download Center (PCDC) at rok.auto/pcdc
.
This update must be done using Control Flash. It is not possible to do this
update via USB flash drive as can be done with the System Firmware update
To update the DLR Network Switch firmware, follow these steps.
1. On the PanelView terminal, in the Control Panel, select Settings
Firmware Updates / Switch to Firmware Update mode.
2. In the DLR Network Switch Firmware section, click Start Update
Utility.
3. In the Warning dialog box, click the OK button to proceed with the
firmware update.
(1) Series C for Stainless Steel terminals.
