Rockwell Automation Publication 2711P-UM008I-EN-P - February 2022 177
Chapter 6
Install and Replace Components
Topic Page
Connect to USB Ports 178
Install a USB Printer 179
Insert an SD Card 183
Connect a Speaker 184
Replace the Battery 185
Install a Protective Overlay 187
Replace the Stainless Steel Terminal Gasket 189
Install and Replace Components in the ArmorView Plus 7
Performance terminal.
See the ArmorView Plus 7 Installation Instructions,
publication 2711P-IN013
.
ATTENTION: Prevent Electrostatic Discharge (ESD)
This equipment is sensitive to electrostatic discharge, which can cause internal
damage and affect normal operation.
Follow these guidelines when you handle this equipment:
• Touch a grounded object to discharge potential static.
• Wear an approved grounding wrist strap.
• Do not touch connectors or pins on component boards.
• Use a static-safe workstation, if available.
ATTENTION: Disconnect all power before installing or replacing any
components. Failure to remove power can result in electrical shock or
damage to the terminal.
At the end of its life, this equipment should be collected separately from any
unsorted municipal waste.
TIP For a complete list of supported devices, go to
https://rockwellautomation.custhelp.com
and search the Knowledgebase
for keywords ‘PanelView Plus Hardware Compatibility List’.
