Rockwell Automation Publication 2711P-UM008I-EN-P - February 2022 9
Preface
Summary of Changes
This manual describes how to install, configure, operate, and troubleshoot the
PanelView™ Plus 7 Performance terminals. It does not provide procedures on how
to create applications that run on the terminals or ladder logic that runs in the
controller.
This manual contains new and updated information as indicated in the following
table.
Other tasks that you must do include:
• Create a human machine interface (HMI) application for the terminal by
using FactoryTalk® View Machine Edition (ME) software, version 8.x or
later.
• Create ladder logic for the controller by using the Studio 5000 Logix
Designer® application.
Note: This document does not provide instructions on how to install and
configure components of the ArmorView Plus 7 product. For instructions on
how to do that, see the ArmorView Plus 7 Installation Instructions, publication
2711P-IN013
.
Package Contents
This product is shipped with these items:
• PanelView Plus 7 Performance terminal
• Series A: With FactoryTalk View ME Station runtime software
installed and activated
• Series B: With factory default firmware (must be updated with
FactoryTalk View ME Station runtime software prior to deploying to
production network)
• Removable power terminal block
• Product information
• Cutout template
• Quick start guide (Series B only
(1)
)
• Mounting levers for panel installation (for aluminum terminals)
• Mounting clamps for panel installation (for stainless steel terminals)
• Backing plate (for stainless steel terminals)
• Hygienic gasket, blue (for stainless steel terminals)
For information on what is shipped with the ArmorView Plus 7 terminal, see the
ArmorView Plus 7 Installation Instructions, publication 2711P-IN013
.
Topic Pages
Added information about the PanelViw Plus 7 Performance, Series B terminals Throughout
(1) Series C for PanelView Plus 7 Performance Stainless Steel terminals.
