24 Rockwell Automation Publication 2711P-UM008I-EN-P - February 2022
Chapter 1
Ethernet Cables
See the Industrial Ethernet Media Brochure, publication 1585-BR001, for
recommended Ethernet cables and media solutions.
See the USB to Serial Adapter Quick Start Guide, publication
GMSC10-QS003
, for information on USB to serial port adapters.
Table 9 - Secure Digital (SD) Cards
(1)
(1) To help reduce the chance of corruption when you use SD Cards or USB drives with the terminal, Rockwell Automation
recommends that you use only the above SD card catalog numbers.
Cat. No. Description Quantity
1784-SD1 1 GB SD card 1
1784-SD2 2 GB SD card 1
1784-SDHC8 8 GB High Capacity SD card 1
1784-SDHC32 32 GB High Capacity SD card 1
2711C-RCSD USB to SD adapter for SD card 1
Table 10 - Battery Replacement
Cat. No. Description Quantity
2711P-RY2032 Lithium coin-cell battery, CR2032 equivalent 1
IMPORTANT Before you select the appropriate replacement gasket, you must identify the
series of the PanelView Plus 7 Performance Stainless Steel terminal. The
terminal’s series information is located on the terminal’s product nameplate
label. In the following table, gaskets that are listed for use on Series B or C
terminals are not certified for use on Series A terminals, and gaskets that are
listed for use on Series A terminals are not certified for use on Series B or C
terminals.
Table 11 - Hygienic Gasket Replacement Kits for Stainless Steel Terminals
Cat. No. Description
(1)
(1) Gasket material is compliant with FDA 21 CFR 177.2600.
Terminal
Series
Quantity
2711P-RGST9W
Hygienic gasket, blue silicone
For 9-in. Series A Stainless Steel Terminals
A1
2711P-RGST12W
Hygienic gasket, blue silicone
For 12-in. Series A Stainless Steel Terminals
A1
2711P-RGST9WB Hygienic gasket, blue, silicone, with ribs
For 9-in. Series B or C Stainless Steel Terminals
B or C 1
2711P-RGST12WB Hygienic gasket, blue, silicone, with ribs
For 12-in. Series B or C Stainless Steel Terminals
B or C 1
