3C-15 Transfer: Motor-Shift Type (Transfer with Shift Actuator)
4 ) Visual inspection
1) Perform visual inspection.
Is there any faulty condition?
Repair or replace
malfunction part. Go to
Step 11.
Go to Step 8.
5 ) Trouble symptom confirmation
1) Shift transfer to “4H”, “4H-lock”, “4L-lock” and “N”
positions referring to “4WD Control System Operation
Inspection: Motor-Shift Type (Transfer with Shift
Actuator)”.
2) Confirm trouble symptom.
Is trouble symptom identified?
Go to Step 6. Go to Step 7.
6 ) Rechecking and record of DTC / freeze frame data
1) Recheck for DTC referring to “DTC Check: Motor-Shift
Type (Transfer with Shift Actuator)”.
Is there any DTC(s)?
Go to Step 9. Go to Step 8.
7 ) Rechecking and record of DTC / freeze frame data
1) Recheck for DTC referring to “DTC Check: Motor-Shift
Type (Transfer with Shift Actuator)”.
Is there any DTC(s)?
Go to Step 9. Go to Step 10.
8 ) 4WD control symptom diagnosis
1) Check and repair according to “4WD Control Symptom
Diagnosis: Motor-Shift Type (Transfer with Shift
Actuator)”.
Are check and repair complete?
Go to Step 11. Check and repair
malfunction part(s). Go
to Step 11.
9 ) Troubleshooting for DTC
1) Check and repair according to applicable DTC flow.
Are check and repair complete?
Go to Step 11. Check and repair
malfunction part(s). Go
to Step 11.
10 ) Check for intermittent problems
1) Check for intermittent problems.
Is there any faulty condition?
Repair or replace
malfunction part(s). Go
to Step 11.
Go to Step 11.
11 ) Final confirmation test
1) Clear DTC if any.
2) Perform final confirmation test.
Is there any problem symptom, DTC or abnormal condition?
Go to Step 6. End.
Step Action Yes No
