Transfer: Non-Shift Type (Transfer without Shift Actuator) 3C-78
Repair Instructions
Transfer Oil Change
S5JB0E3326001
Refer to “Transfer Oil Change: Motor-Shift Type (Transfer with Shift Actuator)”.
The point which is different from the motor-shift type (transfer with shift actuator) is described.
Transfer oil capacity (Reference)
: 1.6 liters (3.4/2.8 US/lmp.pt)
Transfer Oil Level Check
S5JB0E3326002
Refer to “Transfer Oil Level Check: Motor-Shift Type (Transfer with Shift Actuator)”.
Transfer Oil Seal Removal and Installation
S5JB0E3326003
Refer to “Transfer Oil Seal Removal and Installation: Motor-Shift Type (Transfer with Shift Actuator)”.
Transfer Assembly Dismounting and Remounting
S5JB0E3326004
Refer to “Transfer Assembly Dismounting and Remounting: Motor-Shift Type (Transfer with Shift Actuator)”.
To Next Page
