1A-70 Engine General Information and Diagnosis:
11 A/C compressor control system check
Is A/C compressor started when A/C and blower speed
selector switch are turned ON with engine running?
A/C system is in good
condition.
Go to Step 12.
12 A/C compressor relay circuit check
1) Measure voltage between “E23-49” wire terminal of
ECM connector and vehicle body ground under following
conditions respectively.
Voltage between “E23-49” terminal of ECM
connector and ground
While engine running and A/C switch turned OFF: 10
– 14 V
While engine running, A/C and blower speed
selector switch turned ON: 0 – 1 V
Is check result satisfactory?
Go to Step 13. Go to Step 14.
13 A/C compressor relay check
1) Check A/C compressor relay referring to “A/C
Compressor Relay Inspection: in Section 7B in related
manual”.
Is it in good condition?
A/C compressor drive
circuit malfunction.
Replace A/C
compressor relay.
14 A/C compressor relay circuit check
1) Remove A/C compressor relay with ignition switch
turned OFF.
2) Turn ON ignition switch, measure voltage between “YEL/
GRN” wire terminal of A/C compressor relay connector
and vehicle body ground.
Is voltage 10 –14 V?
Go to Step 15. “YEL/GRN” wire is open
circuit.
15 A/C compressor relay check
1) Check A/C compressor relay referring to “A/C
Compressor Relay Inspection: in Section 7B in related
manual”.
Is it in good condition?
“PNK” wire is open
circuit. If OK, substitute
a known-good ECM and
recheck.
Replace A/C
compressor relay.
Step Action Yes No
