ABS: 4E-8
Diagnostic Information and Procedures
ABS Check
S5JB0E4504001
Refer to the following items for the details of each step.
Step 1: Malfunction Analysis
Customer complaint analysis
Record details of the problem (failure, complaint) and how it occurred as described by the customer.
For this purpose, use of such a questionnaire form as shown in the following will facilitate collecting information to the
point required for proper analysis and diagnosis.
Step Action Yes No
1 ) Malfunction analysis
1) Perform “Customer complaint analysis: ”.
2) Perform “Problem symptom confirmation: ”.
3) Perform “DTC check, record and clearance: ” and
recheck DTC.
Is there any malfunction DTC?
Go to Step 4. Go to Step 2.
2 ) Driving test
1) Perform “Step 2: Driving Test: ”.
Is trouble symptom identified?
Go to Step 3. Go to Step 6.
3 ) DTC check
1) Perform “DTC Check: ”.
Is it malfunction code?
Go to Step 4. Go to Step 5.
4 ) ABS check
1) Inspect and repair referring to applicable DTC flow.
Does trouble recur?
Go to Step 5. Go to Step 7.
5 ) Brakes diagnosis
1) Inspect and repair referring to “Brakes Symptom
Diagnosis: in Section 4A”.
Does trouble recur?
Go to Step 3. Go to Step 7.
6 ) Intermittent problem check
1) Check intermittent troubles referring to “Intermittent and
Poor Connection Inspection: in Section 00 in related
manual” and related circuit of trouble code recorded in
Step 1.
Does trouble recur?
Go to Step 4. Go to Step 7.
7 ) Final confirmation test
1) Perform “Step 7: Final Confirmation Test: ”.
Does trouble recur?
Go to Step 3. End.
To Next Page
