Automatic Transmission/Transaxle: 5A-34
Repair Instructions
Automatic Transmission Unit Components
S5JB0E5106027
(b)
(c)
(c)
(c)
(c)
(d)
(e)
17
16
9
9
(c)
9
15
8
7
4
3
5
6
10
11
12
18
19
21
20
(a)
2
(a)
1
23
(b)
24
(b)
13
14
A
(a)
22
(b)
13
14
[A]
I5JB0D510006-01
[A]: View A 8. Drive plate cover 16. Oil filler tube bolt 24. Engine earth cable bolt
1. Torque converter mounting bolt No.1
: After tightening torque converter
mounting bolt No.1, tighten torque
converter mounting bolt No.2.
9. Engine to transmission bolt 17. Oil filler tube : 65 N⋅m (6.5 kgf-m, 47.0
lb-ft)
2. Torque converter mounting bolt No.2 10. Exhaust pipe No.2 bracket 18. Input shaft speed sensor : 10 N⋅m (1.0 kgf-m, 7.5
lb-ft)
3. Drive plate 11. Transmission to engine bolt 19. Output shaft speed sensor : 80 N⋅m (8.0 kgf-m, 58.0
lb-ft)
4. Torque converter 12. Exhaust pipe No.2 bracket bolt 20. Transmission wire connector : 50 N⋅m (5.0 kgf-m, 36.5
lb-ft)
5. Oil cooler hose 13. Harness bracket bolt 21. Output shaft speed sensor : 23 N⋅m (2.3 kgf-m, 17.0
lb-ft)
6. Clamp 14. Harness bracket 22. Drive plate bolt
7. Drive plate cover bolt 15. Transmission 23. Engine earth cable
To Next Page
